22 Part Number 040005626 5/17
Ice Machine Clearance Requirements
Clearance Requirements
Do not obstruct ice machine vents or
openings
M0420
M0500 -M0
700
M1000 -
M1400
Self-Contained
Air-Cooled
Water-Cooled
and
Remote*
Top/Sides 8" (20.3 cm) 8" (20.3 cm)
Back 5" (12.7 cm) 5" (12.7 cm)
*There is no minimum clearance required for water-cooled
or remote ice machines. This value is recommended for
efficient operation and servicing only.
The ice machine must be protected if it will
be subjected to temperatures below 32°F
(0°C). Failure caused by exposure to
freezing temperatures is not covered by the
warranty.
