Manitowoc MD0420A User Manual

46 Part Number 040005626 5/17
* Condenser Fan Motor: The fan motor is wired through a fan cycle pressure control; therefore, it may cycle on and off.
4. Freeze
ON OFF ON OFF ON OPEN
THEN
CLOSED
CLOSED
THEN
OPEN
Until
Harvest
Float Switch
closes for
10 continual
seconds
Harvest
Sequence
5. Water Purge
ON ON OFF ON ON CLOSED CLOSED
45 seconds
6. Harvest
OFF ON OFF OFF ON CLOSED CLOSED
Bin switch
activation
7. Automatic
Shut-off
OFF OFF OFF OFF OFF CLOSED CLOSED
Until bin
switch
re-closes
