LUBRICATION GUIDE MLC80A-1/MLC90A-1/MLC100A-1/MLC100-1
F2314-6
07-20-21
FLUID CAPACITIES
The fluid capacities given in Table 3 are approximate and should be used only as a guide for
ordering sufficient fluid at oil change intervals.
Always fill each system to level plug opening or to specified point on the sight gauge or the dipstick.
Do not overfill. Do not mix mineral oil with synthetic oil.
Table 3
System
Capacity
Lubricant Spec ID
See Table 1
or Table 2
US Metric
Cooling System 7.5 gal 28,4 L C
Crawler Gearbox (2 places) 4 gal 15 L B
Crawler Intermediate Roller (11 each crawler) 6 oz 175 cc
Crawler Top Roller (2 each crawler) 0.3 oz 10 cc
DEF Tank 10 gal 38 L J
Drum 1 and 2 (without free fall) 2.6 gal 9,7 L G
Drum 1 and 2 (with free fall) 4.6 gal 17,5 L G
Drum 3 (Auxiliary Hoist) 5.3 gal 20 L G
Drum 4 (Boom Hoist) 1.3 gal 5,1 L G
Engine (QSB6.7 Tier 3 and Tier 4F) 5 gal 17 L E
Fuel (ultra low sulfur) 100 gal 379 L See Engine Manufacturer’s Manual
Hydraulic Tank (to full cold mark) 67 gal 254 L H
Hydraulic System 188 gal 710 L H
Swing 1.3 gal 5 L G
Tagline See decal on each tagline barrel for data.
Windshield Washer Fluid Tank 1 gal 4 L Non-Freezing Washer Fluid
