Manitowoc Q210 series User Manual

Part Number 80-01111-9 7/10 209
Q130 SELF-CONTAINED AIR-COOLED 
(Before Serial Number 310047287)
NOTE: These characteristics may vary depending on
operating conditions.
Cycle Times
Freeze Time + Harvest Time = Total Cycle Time
Times in minutes
24 Hour Ice Production
Based on average ice slab weight of 1.06-1.19 lb (481 – 540 g).
Regular cube derate is 7%
Operating Pressures
Suction pressure drops gradually throughout the freeze cycle
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
70/21 10.2-11.7 12.4-14.1 14.6-16.5
1.0-2.5
80/27 11.2-12.8 13.0-14.8 15.5-17.5
90/32 13.0-14.8 15.5-17.5 17.6-19.9
100/38 14.6-16.5 17.6-19.9 20.3-23.0
Air Temp.
Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10.0 70/21.1 90/32.2
70/21.1 130 110 95
80/26.7 120 105 90
90/32.2 105 90 80
100/37.8 95 80 70
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
50/10 220-255 54-20 150-180 80-110
70/21 220-270 54-20 160-190 90-115
80/27 220-300 56-22 180-200 100-120
90/32 250-340 58-24 190-210 110-130
100/38 280-380 60-26 220-240 120-140
110/43 290-400 62-28 230-260 120-160
