232 Part Number 80-01111-9 7/10
SM50 Tubing Schematic
HEAT
EXCHANGER
COMPRESSOR
DRIER
EVAPORATOR
HOT GAS SOLENOID
VALVE
CONDENSER
CAP TUBE
