5-3
Section 5 Component Parts – Removal & Replacement
Gearmotor Shaft Seal Replacement (continued)
8 Press the bin insulator plate back into place.
9 Replace the three bolts. Using a 7/16” nut
driver, tighten a quarter turn past tight.
10 Replace the paddle wheel, agitator and
paddle wheel pin in the dispenser.
11 Refill the dispenser or restart the ice
machine.
12 Restore power to the dispenser and ice
machine.
