–55–
WATER DISTRIBUTION TUBE
1. Disconnect the water hose from the distribution
tube.
2. Loosen the thumbscrews, which secure the
distribution tube.
3. Lift the end of the distribution tube with the hose
fitting up, and then slide it back and to the right.
!
Caution
Do not force this removal. Be sure the locating tab is
clear before sliding the distribution tube back.
SV1620
WATER DISTRIBUTION TUBE REMOVAL
THUMBSCREW
DISTRIBUTION
TUBE
1. LIFT UP.
2. SLIDE BACK.
3. SLIDE TO RIGHT.
THUMB-
SCREW
1
2
3
