–72–
CVD1875/CVD2075
ACCESS VALVES
CVD1875 SHOWN
CONDENSER
FAN MOTOR
AIR CONDENSER
HEAD PRESSURE
CONTROL VALVE
COMPRESSOR
SUCTION
ACCUMULATOR
LIQUID LINE AND
SUCTION LINE
CONNECTION POINTS
ELECTRICAL
COMPARTMENT
