Manitowoc RFF Series - Page 111

Part Number 000015433_05 3/21 111

1 Gear motor
2 Compressor
4 Condenser fan motor
6 Water inlet valve
10 Low water level safety
11 Bin thermostat
12 High temperature limit (snap disc)
13 Fan cycle control
15 Contactor
17 Water level switch
24 On/Off switch
27 Low pressure safety switch

WH White
BU Blue
GY Grey
BN Brown
BK Black
RD Red
PK Pink
