88 Part Number 000015433_05 3/21
FILTER-DRIERS
The size of the filter-drier is important. The refrigerant
charge is critical. Using an improperly sized filter-drier
will cause the ice machine to be improperly charged with
refrigerant.
Important
Driers are covered as a warranty part. The drier must be
replaced any time the system is opened for repairs.
SUCTION CLEANUP FILTER-DRIER
Contaminated systems must have a suction line filter-drier
installed to remove contaminations. An access valve must
be installed on the inlet side of the suction filter to allow
pressure drop readings to be obtained.
Suction Line Clean-Up Filter
Model Drier Size End
Connection
Size
All Models UK-165S 5/8 in.
