Manitowoc RFF Series User Manual

Part Number 000015433_05 3/21 117

1 Gear motor
2 Compressor
6 Water inlet valve
10 Low water level switch
11 Bin thermostat
15 Contactor
17 Water level switch
18 Chute safety switch
19 High pressure safety switch
24 On/Off switch
27 Low pressure safety switch
30 Rotation sensor
35 Compressor time delay by-pass

WH White
BU Blue
GY Grey
BN Brown
BK Black
RD Red
PK Pink

Manitowoc RFF Series Specifications

General

Brand	Manitowoc
Model	RFF Series
Category	Ice Maker
Language	English
