Manitowoc RFF Series - Page 125

Part Number 000015433_05 3/21 125

1 Gear motor
6 Water inlet valve
10 Low water level safety
11 Bin thermostat
17 Water level switch
18 Ice chute safety switch
24 On/Off switch
30 Rotation sensor
35 Compressor time delay by-pass
38 Solenoid valve
50 Relay

WH White
BU Blue
GY Grey
BN Brown
BK Black
RD Red
OG Orange
