Part Number 000015433_05 3/21 127
1 Gear motor
2 Compressor
4 Condenser fan motor
6 Water inlet valve
10 Low water level safety
11 Bin thermostat
13 Fan cycle control
15 Contactor
17 Water level switch
18 Ice chute safety switch
19 High pressure safety switch
21 Compressor relay
24 On/Off switch
25 Compressor time delay
27 Low pressure cut out
29 Compressor time delay relay
30 Rotation sensor
35 Compressor time delay by-pass
37 Remote indicator panel terminals
38 Solenoid valve
Rc Compressor crankcase heater
WH White
BU Blue
GY Grey
BN Brown
BK Black
RD Red
PK Pink
