Manitowoc RFF Series User Manual

Part Number 000015433_05 3/21 131

1 Gear Motor
2 Compressor
4 Condenser fan motor
6 Water inlet valve
7 Evaporator low temperature safety thermostat
10 Low water level safety
11 Bin thermostat
13 Fan cycle control
15 Contactor
17 Water level switch
18 Ice chute safety switch
19 High pressure cut out
24 On/Off switch
25 Compressor time delay
35 Compressor time delay by-pass

WH White
BU Blue
GY Grey
BN Brown
BK Black
RD Red
PK Pink

Manitowoc RFF Series Specifications

General

Brand	Manitowoc
Model	RFF Series
Category	Ice Maker
Language	English
