Manitowoc RFF Series - Page 135

Part Number 000015433_05 3/21 135

1 Gear Motor
2 Compressor
6 Water inlet valve
10 Low water level safety
11 Bin thermostat
15 Contactor
17 Water level switch
18 Ice chute safety switch
19 High pressure cut out
24 On/Off switch
27 Low pressure cut out
30 Rotation sensor
35 Compressor time delay by-pass

WH White
BU Blue
GY Grey
BN Brown
BK Black
RD Red
PK Pink
