Part Number 000015433_05 3/21 163
1 Compressor
2 Check Valve
3 Head Pressure Control Valve
4 Condenser
5 Receiver
6 Condensing unit Liquid Line Drier
7 Liquid Line Shut-off Valve
8 Ice Machine Liquid Line Drier
9 Liquid Line Solenoid Valve
10 Thermostatic Expansion Valve
11 Evaporator
12 S Trap (20’ + Rise Only)
13 Suction Line Shut-off Valve
14 Suction Line Filter
15 Suction Accumulator
NOTE: Dotted rectangle indicates ice machine head
section.
