Step 2 Time delay cycle normal light operation

The bin fills with ice, the Low Bin light de-energizes

and the Time delay light energizes. The compressor

and gear motor immediately turn off and the

condenser fan continues to run for 10 minutes before

turning off. When the time delay ends and the Low bin

light energizes the ice machine will restart.

Step 3 Purge cycle normal light operation

After 1 to 2 hours of ice making the control board will

initiate a purge cycle. The compressor de-energizes

and the gear motor and condenser fan motor continue

to run. After the purge cycle is complete the ice

machine starts without a time delay period.

PURGE (Y)

POWER (G)

LOW BIN (G)

AUGER ON (G)

REFRIG ON (G)

CLEANING (Y)

SERVICE (R)

HI AMPS (R)

HI PRESS (R)

LO PRESS (R)

DRAIN CLOG (R)

TIME DELAY (Y)

LO WATER (R)

CPU (G)

HI WATER (R)
