Head Section Drains
³ Install 18” Vent Tubes
³Ice Machine & Bin drains must be run separately
³ Drains Must:
³Be run separately
³Have a minimum pitch of
1.5 inches every 5 feet
³ Floor Drain must be large
enough to accommodate
drainage from all drains
