WATER SUPPLY AND DRAIN LINE SIZING/
CONNECTIONS
Location
Water
Temperature
Water
Pressure
Ice Machine
Fitting
Tubing Size Up
to Ice Machine
Fitting
Ice Making
Water Inlet
40°F (4°C) min.
90°F (32°C) max.
20 psi (138 kPa) min.
80 psi (550 kPa) max.
3/8” Female
Pipe Thread
3/8" (9.5 mm) min.
inside diameter
Condenser
Water Inlet
40°F (4°C) min.
90°F (32°C) max
20 psi (1.38 bar) min.
150 psi (10.3 bar) max.
3/8” Female
Pipe Thread
3/8" (9.5 mm) min.
inside diameter
Condenser
Water Drain
——
3/8” Female
Pipe Thread
3/8" (9.5 mm) min.
inside diameter
