Operational Analysis 1 2 3 4
Harvest Valve
The harvest valve
inlet is
HOT
and
The compressor
discharge line is
HOT
The harvest valve
inlet is
COOL
and
The compressor discharge line is
HOT
The harvest valve
inlet is
COOL
and
The compressor
discharge line is
COOL
The harvest valve
inlet is
COOL
and
The compressor discharge line is
HOT
Discharge Line Temp.
Record freeze cycle
discharge line temp at the
end of freeze cycle.
Discharge line temp
150°F (66°C) or higher
at the end of freeze cycle
Discharge line temp
150°F (66°C) or higher
at the end of freeze cycle
Discharge line temp
less than 150°F (66°C)
at the end of freeze cycle
Discharge line temp
150°F (66°C) or higher
at the end of freeze cycle
Final Analysis
Enter total number of boxes
checked in each column.
Harvest Valve
Leaking
Low On Charge
-or-
TXV Starving
TXV Flooding Compressor
