UG040A-261 SELF-CONTAINED AIR-COOLED — STANDARD CUBE

NOTE: These characteristics may vary depending on operating conditions.

Cycle Times

Freeze Time + Harvest Time = Total Cycle Time

Air Temp.

Entering

Condenser

°C

Freeze Time

Harvest Time

Times in minutes.

Water Temperature °C

10 15 21 32

10 21.76-24.29

1.6-4.0min.

21 20.16-22.36

32 23.64-26.88

38 30.82-34.61

43 39.08-41.89

Default Chapter7
