Manitowoc UG050A Technician's Handbook

–108–
UG050A-251 SELF-CONTAINED AIR-COOLED — STANDARD CUBE (Continued)
Operating Pressures
Air Temp. Entering
Condenser °C
Freeze Cycle Harvest Cycle
Discharge Pressure Suction Pressure Discharge Pressure
Suction Pressure
All pressures are in bar. Suction pressure drops gradually throughout the freeze cycle.
10 12.00-10.60 3.51-1.37 7.22-8.22 4.78-6.34
21 15.62-12.69 3.90-1.42 8.64-10.16 6.32-7.93
32 20.24-18.37 4.75-1.67 11.53-12.70 7.60-10.13
43 25.50-23.00 4.84-1.65 12.25-14.20 9.00-11.56
