Part Number: 040003628 Rev. 01 01/14/18 3-1
Section 3
Operation
Component Identification
Water
Curtain
Water Sump
Trough
Air-Cooled
Condenser
ON/OFF/WASH
Toggle Switch
Control Board
Evaporator
Ice Chute
Spray
Nozzles
Spray Bar
Toggle Switch
