Manitowoc URF0140A Technician's Handbook

Part Number 000014797 Rev02 05/18 45
Step 5 Wait until the clean cycle is complete
(approximately 45 minutes) then place the toggle switch in
the Off position and disconnect power and water supplies
to the ice machine.
n
Warning
Disconnect electric power to the ice machine at the
electric switch box before proceeding.
Step 6 Remove parts for cleaning.
A. Remove the Overflow Tube
• To remove the tube, lift it up while using a slight back
and forth motion to loosen it from the drain hole.
When installing the tube, be sure it is completely inserted
into the drain hole to prevent water leakage during normal
operation.
B. Remove vinyl hose.
• Disconnect the water pump discharge hose from the
distribution tube and water pump.
