Electronic Control Board UF Models
Number Component
1 LED Water Pump Relay
2 LED Compressor Relay
3 LED Water Dump Valve Relay
4 LED Harvest Solenoid Valve
5 LED Clean
6 LED Thermistor
7 LED Thermistor
8 LED Thermistor
9 LED Water Fill Valve
10 LED Harvest Float
11 LED Water Level Float
12 LED Bin Switch
13 LED Safety Limit 2
14 LED Safety Limit 1
15 LED Harvest
16 LED Test Mode
17 Fuse
18 Motor Connector 12V - J8
19 EC Fan Motor Connector 12V - J9
20 Bin Switch Connector - J5
21 Float Switch Water Level
22 Float Switch Harvest
23 Thermistor 2 - J10
24 Test Switch
25 Thermistor 1 - J4
