MANN+HUMMEL ProVent 100 - ProVent 200 Element Change

MANN + HUMMEL ProVent
MANN+HUMMEL Industrial Filters 15
• Pull the old oil separator element off the lid
and dispose of properly.
• Mount the new replacement element in the
ProVent. Ensure correct seating.
• Lay on the lid and turn it to the desired
position.
• Reconnect the drain hose.
Fig. 13
Changing oil separator of ProVent 150
ProVent 200
• Screw off the lid in the direction of the arrow
of the lid marking. If the lid is difficult to
remove, use a suitable aid (see Fig. 14)
Fig. 14 Detaching lid of ProVent 200
• Remove the old oil separator element and
dispose of it properly.
• Mount the new replacement element in the
ProVent. Ensure correct seating.
• Lay on the lid and turn it opposite the
direction of the arrow on the lid marking until it
engages.
Fig. 15 Changing oil separator of ProVent 200
