Mantis COMPACT ComposTumbler CT02001 User Manual

8
4.1 4.2
5.1 5.2
5.3
Place the second endcap on the open end of the
assembled drum. Note that when the endcap
is properly aligned, the vent openings will be on
oppositesidesofthesamecentermixingn.
Thread an acorn cap nut onto one end of each of the tie
rods (2-3 turns only) and insert the rods trough the holes in
the end cap. Guide the other end of each tie rod through the
hole in the opposite endcap. Reach out under the endcap
and thread acorn cap nuts over the other ends of the tie
rods. Tighten all acorn cap nuts with the wrenches.
Insert a 3-1/4” long Hex head
cap screw through the aerator
base and position the two pieces
on the outside of the door as
shown below.
Slide the aerator cap over the
hex head screw and fasten with
thewingnut(ngertightonly)
Repeat steps 5.1 and 5.2 with the second aerator base and cap.
WHAT YOU’LL NEED
Tools: None
Hardware: 5a - (2) ¼-20 x 3-1/4” Hex head cap screws
5b - (2) ¼-20 Wing nuts
Parts: Item 3 - (1) Door
Item 5 - (2) Aerator base
Item 6 - (2) Aerator cap
STEP 5 – ENDCAP INSTALLATION
Aerator Base
Aerator Cap
