ITEM NO. PART NO. DESCRIPTION QTY
1 520100 CART BOTTOM ASSEMBLY
WELDED AND PAINTED 1
2 520500 M10, CARRIAGE BOLT, SQ NECK,
60MM LG 2
3 520101 KNOB 2
4 520102 WHEEL 10 INCH DIA 2
5 520103 HANDLE UPPER SUB-ASSEMBLY
PAINTED 1
6 520104 STABILIZING BAR/PIVOTING SUPPORT 1
7 520105 CONNECTING LINK 2
8 520501 BOLT HEX M6 X 40MM 2
9 520502 NUT LOCK M6, NYLON INSERT 6
10 520106 SOLENOID PROTECTION BRACE 1
11 520503 WASHER #6 4
12 520504 BOLT HEX M6 X 15MM 2
13 520107 END CAP 2
14 520505 BOLT HEX M6 X 30MM 2
15 520108 PROTECTIVE BRACE 1
16 520506 WASHER 4MM DIA 4
17 520507 SCREW M4 X 35MM 2
18 520508 NUT M4 2
19 520109 SWITCH BOX ASSEMBLY 110V
WITH STRAIN RELIEF OPENING 1
20 520509 NUT M16 (THIN) 2
21 520110 MOTOR ASSEMBLY 110V 1
22 520111 HYDRAULIC ASSEMBLY 1
23 510601 WARNING LABEL 1
24 520112 DIP STICK 1
25 520113 DIP STICK SEAL 1
26 520114 AIR BLEED SCREW 1
27 520115 DRAIN PLUG SEAL 1
28 520116 WHEEL SHAFT 2
29 520510 M14 WHEEL NUT 2
30 520134 SWITCH BOX ASSEMBLY 110V
WITHOUT STRAIN REL OPENING 1
31 520117 CABLE TIE 152MM (6”) LONG 1
ITEM NO. PART NO. DESCRIPTION QTY
32 510600 SWIFT SPLIT LOGO LABEL 2
33 520118 SWITCH PROTECTIVE COVER 2
41 520200 BLEED SCREW SEAL 1
61 520220 DRAIN PLUG, M10 X 8MM THREAD 1
111 520516 ALLEN WRENCH #8 (DRAIN PLUG) 1
520109 SWITCH BOX ASSEMBLY WITH
STRAIN RELIEF OPENING
34 520119 SWITCH BOX 1
35 520120 SWITCH BOX COVER 1
36 520121 SWITCH 110V 1
37 520122 STRAIN RELIEF (SWITCH BOX) 1
38 520511 SCREW SELF TAPPING 3.2X16 LONG 4
520134 SWITCH BOX ASSEMBLY WITHOUT
STRAIN RELIEF OPENING
114 520135 SWITCH BOX WITHOUT STRAIN
REL OPENING 1
35 520120 SWITCH BOX COVER 1
36 520121 SWITCH 110V 1
38 520511 SCREW SELF TAPPING 3.2X16 LONG 4
MOTOR ASSEMBLY
97 520110 MOTOR, 110V 1
98 520123 WIRE CLAMP 1
99 520124 15 AMP CIRCUIT BREAKER 1
100 520514 C/B NUT 1
37 520122 STRAIN RELIEF (SWITCH BOX) 1
102 520126 CORD (OUTDOOR USE) 1
37 520122 STRAIN RELIEF (SWITCH BOX) 1
104 520128 RUBBER FEET COVER 2
105 520129 CAPACITOR 300VAC 1
107 520130 GASKET (MOTOR JUNCTION BOX) 1
108 520131 MOTOR JUNCTION BOX 1
109 520132 LID 1
38 520511 SCREW SELF TAPPING 3.2X16 LONG 8
113 520133 STRAIN RELIEF 1
19
O. Parts List
