Preparation
KMP-032X
4 inch (10 cm)
4 inch (10 cm)
• Place the compressor in a suitable location.
The air vent at the back of the compressor
must not be covered or blocked
Do not place the compressor near a
radiator or heating unit, since the
operating temperature might increase
and activate the temperature alarm.
-
- When the compressor is used as a
standby unit, connect the central
compressed air supply to the air inlet on
the compressor.
- Check that an empty drainage bottle is
fitted.
- MAQUET Compressor Mini mounting
kits are mandatory for both stand-alone
arrangements and for mounting on carts.
The mounting kits ensure that there is
sufficient air circulation around the
compressor.
Connection
KMP-052X
0
OUT
IN
OUT
IN
• Connect the compressed air hose from the
compressor air outlet to the ventilator.
Plug in the compressor mains cable to
a grounded outlet.
-
Start-up
A function check should be done before the
unit is put into use, and once a week when in
continuous use.
Caution: If a fault is discovered during the
function check, the compressor must not be
used until it has been repaired by authorized
service personnel.
