Marantz 4070 - Page 21

MARANTZ
PART NO.
DESCRIPTION
288516040
288516001
YT0208002
YT0208002
YJ0400018
YJ0400018
Y¥J0800012
YT0304001
YT0304001
Y¥T0304001
YT0304001
¥T0101003
51100308S
53110303E
62041760W
§4050400R
51100308S
53110303E
55060365S
51100306S
51100312S
53110303E
51100303S
$S0802007
YJ1100012
288516004
51100306S
53110303E
51100308S
53110303E
Y¥C0240010
FS1030006
$R0702001
YW2885001
YX2885001
288510550
352812002
51100306S
288510902
51570306B
EC 1090351
EC1090351
288516005
51570306B
274726504
288510901
51100306S
51570306B
281900501
51570306B
138200503
51570306B
Bracket Ass'y
Bracket
Terminal, Front Main In, 8P
Terminal, Rear Main In, 8P
Jack, AC Outlet
Jack, AC Outlet
Socket, Fuse Holder
Terminal, Speaker
Terminal, Speaker
Terminal, Speaker
Terminal, Speaker
Terminal, Ground
B.H.M. Screw, Speaker Terminal x8
Hexagon Nut, Speaker Terminal x8
Lug, Earth Terminal
T.L. Washer OR, Earth Terminal
B.H.M. Screw, RCA Pin Terminal x 4
Hexagon Nut, RCA Pin Terminal x 4
T.R. Rivet, AC Socket x4
B.H.M.Screw x4
B.H.M.Screw x2
Hexagon Nut x2
B.H.M.Screw x2
Slide Switch, Remocon
Jack, Remocon
Bracket, Remocon
B.H.M. Screw x2
Hexagon Nut x2
B.H.M. Screw, RCA Pin Terminal x 4
Hexagon Nut, RCA Pin Terminal x 4
AC Cord
Fuse, 3A, 250V, UL
Rotary Switch, BTL
Wire Material
Wire Material
Chassis K
Insulator
B.H.M.Screw x2
Shield
P.H. Tapt Screw x 3
Electroly Cap., 10000uF, 35V
Electroly Cap., 10000uF, 35V
Bracket
P.H. Tapt Screw x 8
Indicator x4
Shield
B.H.M. Screw
P.H. Tapt Screw x 2
Clamper
P.H. Tapt Screw x 2
Ciamper x3
P.H. Tapt Screw x 3
REF. | MARANTZ
DESIG. | PART NO. DESCRIPTION
L001 TS6050107 Power Transf.
1022 53110401E Hexagon Nut x4
1023 54040402N Spring Washer x4
54020401E Flat Washer P
288512003 Insulator
230912001 Insulator
51570306B P.H. Tapt Screw x 8
1014 51570306B P.H. Tapt Screw x 2
51570306B P.H. Tapt Screw x 10
1027 51570306B P.H. Tapt Screw x 4
51110306S B.H.M. Screw x4
274726503 Indicator, Fuse 3A Label
275905701 Leg x4
0313 51100410A B.H.M.Screw x4
0314 54020401A Flat WasherP x4
0315 54040402A Spring Washer x4
511003058 B.H.M. Screw, Tone P.W.B.
281815401 Knob, Push Switch
0115 281815402 Knob, Power Switch
0116 285015401 Knob, Slide Volume x4
0117 285115401 Knob, Slide Volume x4
0118 281815403 Knob, Rotary Volume x 4
51122608E T.H.M.Screw x4
285125701 Lid
0121 257711803 Spacer x3
0423 257711803 Spacer
282717801 Spacer
51100406S B.H.M. Screw
0310 54020401S Flat WasherP x4
0127 285125750 Lid K
51100406S B.H.M. Screw
288526501 Indicator
51100306S B.H.M.Screw x2
257886101 Label, Caution
0212 257886102 Label, Do not Remove
0213 257886103 Label, See Marking ...,
0217 281826506 Indicator, Same as Line.. .,
951110101 Label, UL
952281501 Seriai NoCard x4
F701 FS1030006 Fuse, 3A/250V (UL)
F702 FS1030006 Fuse, 3A/250V (UL)
1202 288585101 Instructions
1209 288585601 Schematic Diagram
1217 281885104 Instructions
1219 282885108 Instructions
288585107 Instructions
257785450 Guarantee Card K
