Specifications
o
Audio amplifier
RMS Power output (20 Hz – 20 kHz simultaneous drive of
both channels) :
70 W x 2 (8 Ω/ohms load)
100 W x 2 (4 Ω/ohms load)
Total harmonic distortion (20 Hz – 20 kHz simultaneous drive
of both channels, 8 Ω/ohms load) :
0.02 %
Frequency response (CD, 1 W, 8 Ω/ohms load) : 5 Hz – 100 kHz ±3 dB
Dumping factor (8 Ω/ohms load, 20 Hz – 20 kHz) : 100 and over
Input sensitivity/impedance: PHONO (MM): 1.6 mV / 47 kΩ/kohms
CD, LINE, RECORDER: 220 mV/16 kΩ/kohms
POWER AMP IN: 1.5 V/15 kΩ/kohms
Output voltage: SUBWOOFER OUT: 220 mV
Maximum allowable PHONO input level (1 kHz) MM : 80 mV
RIAA deviation (20 Hz – 20 kHz) : ±0.5 dB
S/N (IHF-A, 8 Ω/ohms load): PHONO (MM): 87 dB (5 mV input)
CD, LINE, RECORDER: 113 dB (rated output)
POWER AMP IN: 125 dB (rated output)
Tone control: BASS (50 Hz): ±10 dB
TREBLE (15 kHz): ±10 dB
