3
Setup
Connect your speakers
NOTE
Always set the NORMAL/BI-AMP/BTL selector before turning on
the power. If the setting is changed after turning on the power, the
setting will not be applied.
There are 3 modes for connecting this unit with speakers:
• Normal mode
• Bi-amp mode
• BTL mode (Bridge mode)
Set the NORMAL/BI-AMP/BTL selector on the rear panel of this unit
according to the connection mode used.
■Normal mode
Connect your speaker cables between the AMP 10 and your
speakers. This is the default setup, where you simply connect the
speakers directly to the corresponding pair of terminals.
