Video section
0
Standard video connectors
Input/output level and impedance: 1 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz – 10 MHz — 0, –3 dB
0
Color component video connector
Input/output level and impedance: Y signal — 1 Vp-p, 75 Ω/ohms
P
B
/ C
B
signal — 0.7 Vp-p, 75 Ω/ohms
P
R
/ C
R
signal — 0.7 Vp-p, 75 Ω/ohms
Frequency response: 5 Hz – 60 MHz — 0, –3 dB
o
Tuner section
[FM] [AM]
(Note: μV at 75 Ω/ohms, 0 dBf = 1 x 10
–15
W)
Reception frequency range: 87.5 MHz – 107.9 MHz 530 kHz – 1710 kHz
Effective sensitivity: 1.5 μV (14.8 dBf) 20 μV
S/N ratio (IHF-A): Mono: 78 dB
Stereo: 68 dB
HD: 85 dB
85 dB
Distortion (1 kHz): MONO ― 0.1 %
STEREO ― 0.2 %
HD: 0.02 %
0.02 %
