MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1720 4822 265 11183 CON. FLEX FOIL 4 PIN SIDE ENTRY
1800 4822 691 10615 CD DRIVE VAM1201
1801 4822 267 51453 CON. FLEX FOIL 12 PIN SIDE ENTRY
1810 4822 276 13503 TRAY SWITCH
8002 4822 320 12385 FLEX FOIL 4P 100mm (CD Text)
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2720 4822 122 33197 1nF 10% 50V
2722 4822 126 12785 47nF 10% 50V
2761 4822 121 51387 10nF 20% 16V
2764 4822 122 33191 22pF 5% 50V
2765 4822 122 33191 22pF 5% 50V
2766 4822 122 33519 470pF 10% 50V
2767 4822 122 33191 22pF 5% 50V
2802 4822 126 12882 100nF 20% 50V
2809 4822 126 12785 47nF 10% 50V
2814 4822 126 12339 2,2nF 10% 16V
2818 4822 126 12882 100nF 20% 50V
2819 4822 126 12882 100nF 20% 50V
2820 4822 122 10459 560pF 10% 50V
2823 4822 126 12878 1,5nF 10% 16V
2825 4822 122 10466 220pF 10% 50V
2826 4822 122 10466 220pF 10% 50V
2827 4822 122 10466 220pF 10% 50V
2828 4822 122 10466 220pF 10% 50V
2829 4822 122 10466 220pF 10% 50V
2830 4822 122 10466 220pF 10% 50V
2831 4822 126 12785 47nF 10% 50V
2836 4822 126 13098 5,6nF 20% 16V
2837 4822 122 10459 560pF 10% 50V
2838 4822 126 12882 100nF 20% 50V
2839 4822 121 51387 10nF 20% 16V
2840 4822 122 10576 1,8nF 10% 16V
2842 4822 121 51387 10nF 20% 16V
2843 5322 124 41948 0,47 F 20% 50V
2844 4822 124 22726 4,7 F 20% 35V
2845 4822 122 33848 47pF 5% 50V
2847 4822 124 40433 47 F 20% 25V
2848 4822 121 51387 10nF 20% 16V
2849 4822 124 40433 47 F 20% 25V
2850 4822 124 22726 4,7 F 20% 35V
2851 4822 121 51387 10nF 20% 16V
2853 4822 126 12882 100nF 20% 50V
2856 4822 121 70619 22nF 10% 50V
2857 4822 126 11585 22nF 20% 50V
2858 4822 122 33848 47pF 5% 50V
2860 4822 124 22726 4,7 F 20% 35V
2861 4822 122 33191 22pF 5% 50V
2862 4822 122 33191 22pF 5% 50V
2863 4822 124 81286 47 F 20% 16V
2869 4822 126 12882 100nF 20% 50V
2870 4822 126 12785 47nF 10% 50V
2890 4822 122 33191 22pF 5% 50V
2898 4822 126 12882 100nF 20% 50V
2899 4822 124 22726 4,7 F 20% 35V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3720 4822 116 83883 470 5% 0,16W
3721 4822 116 83883 470 5% 0,16W
3722 4822 116 83883 470 5% 0,16W
3723 4822 116 83883 470 5% 0,16W
3724 4822 116 83883 470 5% 0,16W
3725 4822 116 83883 470 5% 0,16W
3726 4822 116 83883 470 5% 0,16W
3727 4822 116 83883 470 5% 0,16W
3728 4822 050 21003 10k 1% 0,6W
3729 4822 116 52195 47 5% 0,5W
3730 4822 116 52283 4,7k 5% 0,5W
3751 4822 116 83872 220 5% 0,5W
3752 4822 116 83872 220 5% 0,5W
3753 4822 116 83872 220 5% 0,5W
3762 4822 116 83872 220 5% 0,5W
3763 4822 116 83872 220 5% 0,5W
3764 4822 116 83872 220 5% 0,5W
3771 4822 116 83883 470 5% 0,16W
3803 4822 050 21003 10k 1% 0,6W
3804 4822 116 52257 22k 5% 0,5W
3807 4822 116 52226 560 5% 0,5W
3815 4822 050 11002 1k 5% 0,2W
3817 4822 116 52283 4,7k 5% 0,5W
3818 4822 116 52239 120k 5% 0,5W
3820 4822 050 11002 1k 5% 0,2W
3825 4822 050 21003 10k 1% 0,6W
3826 4822 050 21003 10k 1% 0,6W
3827 4822 050 21003 10k 1% 0,6W
3828 4822 050 21003 10k 1% 0,6W
3829 4822 050 21003 10k 1% 0,6W
3830 4822 050 21003 10k 1% 0,6W
3832 4822 116 52191 33 5% 0,5W
3833 4822 050 11002 1k 5% 0,2W
3835 4822 116 52264 27k 5% 0,5W
3836 4822 116 52207 1,2k 5% 0,5W
3837 4822 116 83961 6,8k 5% 0,16W
3838 4822 116 52257 22k 5% 0,5W
3839 4822 116 52207 1,2k 5% 0,5W
3840 4822 116 83961 6,8k 5% 0,16W
3841 4822 052 10338 3,3 NFR25
3842 4822 050 21003 10k 1% 0,6W
3843 4822 116 83882 39k 5% 0,5W
3844 4822 050 11002 1k 5% 0,2W
3845 4822 116 83882 39k 5% 0,5W
3846 4822 050 11002 1k 5% 0,2W
3848 4822 050 11002 1k 5% 0,2W
3849 4822 052 10338 3,3 NFR25
3850 4822 050 11002 1k 5% 0,2W
3851 4822 116 52264 27k 5% 0,5W
3852 4822 050 11002 1k 5% 0,2W
3853 4822 116 83961 6,8k 5% 0,16W
3854 4822 116 83878 270k 5% 0,5W
3856 4822 116 52257 22k 5% 0,5W
3857 4822 116 52234 100k 5% 0,5W
3858 4822 116 52175 100 5% 0,5W
3859 4822 116 83872 220 5% 0,5W
3860 4822 116 52175 100 5% 0,5W
3861 4822 116 52175 100 5% 0,5W
3862 4822 116 83866 1M 5% 0,5W
