Marantz CD5000 - Page 28

RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3863 4822 116 83872 220 5% 0,5W
3864 4822 116 52175 100 5% 0,5W
3865 4822 116 83872 220 5% 0,5W
3866 4822 050 21003 10k 1% 0,6W
3867 4822 050 21003 10k 1% 0,6W
3868 4822 050 21003 10k 1% 0,6W
3869 4822 050 21003 10k 1% 0,6W
3870 4822 050 21003 10k 1% 0,6W
3871 4822 116 52176 10 5% 0,5W
3894 4822 116 52176 10 5% 0,5W
3872 4822 116 52175 100 5% 0,5W
3873 4822 050 21003 10k 1% 0,6W
3874 4822 050 21003 10k 1% 0,6W
3875 4822 116 52191 33 5% 0,5W
3876 4822 116 52213 180 5% 0,5W
3879 4822 116 52226 560 5% 0,5W
3881 4822 116 52283 4,7k 5% 0,5W
3882 4822 116 52283 4,7k 5% 0,5W
3883 4822 116 52175 100 5% 0,5W
3890 4822 050 11002 1k 5% 0,2W
3891 4822 050 11002 1k 5% 0,2W
3892 4822 050 23303 33k 1% 0,6W
3893 4822 116 52249 1,8k 5% 0,16W
3895 4822 050 23303 33k 1% 0,6W
3896 4822 116 52219 330 5% 0.5W
3897 4822 116 83883 470 5% 0,5W
COILS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
5804 4822 157 53302 1 H
5810 4822 157 11517 10 H
5860 4822 242 10566 CRYSTAL 8.4672MHz
DIODES
–––––––––––––––––––––––––––––––––––––––––––––––––––––
6888 4822 130 80655 BZX79-F2V4
TRANSISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7822 4822 130 41344 BC337-40
7877 4822 130 40959 BC547B
7878 4822 130 44503 BC547C
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7802 © 4822 209 12636 TDA1302T/N1 HF PRE AMPLIFIER
7819 © 5322 209 11517 PC74HCU04T HF AMPLIFIER
7821 4822 209 16143 LC89170M CD TEXT
7851 4822 209 32852 TDA7073A/N2 SERVO DRIVER
7852 4822 209 32852 TDA7073A/N2 MOTOR DRIVER
7855 © 4822 209 31519 TDA7072A TRAY MOTOR DRIVER
7860 © 4822 209 12752 SAA7378GP SIGNAL PROCESSOR
10-4
ELECTRICAL PARTSLIST CD BOARD
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
ELECTRICAL PARTSLIST HEADPHONE BOARD
––––––––––––––––––––––––––––––––––––––––––––––––––––––
MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1600 4822 267 31453 HEADPHONE SOCKET 6,3mm
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2603 4822 126 11585 22nF 20% 50V
2604 4822 122 33197 1nF 10% 50V
2605 4822 122 33197 1nF 10% 50V
2610 4822 126 12882 100nF 20% 50V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3600 4822 101 21199 POTMETER 2x10KW
3603 4822 116 52244 15k 5% 0,5W
3604 4822 116 52206 120 5% 0,5W
3605 4822 050 21003 10k 1% 0,6W
3606 4822 050 21003 10k 1% 0,6W
3607 4822 116 52244 15k 5% 0,5W
3608 4822 116 52206 120 5% 0,5W
3609 4822 052 10109 10 5% NFR
3611 4822 052 10109 10 5% NFR
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7670 4822 209 83274 NJM4560D
MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
5001 4822 146 11031 TRANSFORMER MAINS for /N
5001 3139 118 32070
4822 146 11032
3139 118 32060
TRANSFORMER MAINS for /T
3139 228 82600 RC07115/02 (Remote Control)
ELECTRICAL PARTSLIST SET
––––––––––––––––––––––––––––––––––––––––––––––––––––––
5001 TRANSFORMER MAINS for /K
5001 TRANSFORMER MAINS for /F
5001 3139 118 32050 TRANSFORMER MAINS for /U
