Marantz CD5000 - Parts Lists - AF Board; Electrical Parts List - AF Board

10-5
MISCELLANEOUS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
1255 4822 071 56301 FUSE T 630mA/250V
1256 4822 071 56301 FUSE T 630mA/250V
1503 4822 267 31729 CINCH SOCKET DIGITAL OUT
1504 4822 265 20553 CINCH SOCKET LINE OUT
1505 4822 130 10845 GP1F32T TOSLINK
CAPACITORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
2250 4822 124 41407 0,47 F 20% 63V
2251 4822 124 11769 220 F 20% 50V
2252 4822 126 11585 22nF 20% 50V
2253 4822 126 11585 22nF 20% 50V
2254 4822 124 11878 4700 F 20% 16V
2255 4822 126 12882 100nF 20% 50V
2256 4822 126 11585 22nF 20% 50V
2257 4822 126 11585 22nF 20% 50V
2258 4822 124 40784 3300 F 20% 16V
2259 4822 124 80144 220 F 20% 25V
2500 4822 126 11585 22nF 20% 50V
2501 4822 124 40433 47 F 20% 25V
2502 4822 124 40433 47 F 20% 25V
2503 4822 121 51387 10nF 20% 16V
2504 4822 121 51387 10nF 20% 16V
2505 4822 122 33519 470pF 10% 50V
2506 4822 122 33519 470pF 10% 50V
2507 2020 012 93432 47 F
100 H
20% 25V
2508 2020 012 93432 47 F 20% 25V
2511 2020 012 93432 47 F 20% 25V
2512 2020 012 93432 47 F 20% 25V
2513 4822 122 33519 470pF 10% 50V
2514 4822 122 33519 470pF 10% 50V
2515 4822 124 40433 47 F 20% 25V
2516 4822 121 51387 10nF 20% 16V
2521 2020 012 93679 220 F 20% 25V
2522 2020 012 93679 220 F 20% 25V
2523 4822 121 51387 10nF 20% 16V
2524 4822 124 40433 47 F 20% 25V
2527 4822 124 40433 47 F 20% 25V
2540 4822 124 81151 22 F 20% 50V
2541 4822 124 21913 1 F 20% 63V
2543 4822 126 12882 100nF 20% 50V
2544 4822 126 11585 22nF 20% 50V
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3251 4822 053 10471 470 5% 1W
3252 4822 053 10471 470 5% 1W
3253 4822 116 52257 22k 5% 0,5W
3254 4822 116 52283 4,7k 5% 0,5W
3255 4822 116 52256 2,2k 5% 0,16W
3256 4822 050 11002 1k 5% 0,2W
3257 4822 116 52283 4,7k 5% 0,5W
3258 4822 116 52283 4,7k 5% 0,5W
3260 4822 052 10568 5,6 5% 0,33W
3500 4822 116 52289 5,6k 5% 0,16W
3501 4822 050 21003 10k 1% 0,6W
3502 4822 116 52175 100 5% 0,5W
3503 4822 116 52175 100 5% 0,5W
3504 4822 116 52175 100 5% 0,5W
3505 4822 116 52175 100 5% 0,5W
3506 4822 116 52175 100 5% 0,5W
3507 4822 116 52283 4,7k 5% 0,5W
3508 4822 116 52283 4,7k 5% 0,5W
3509 4822 116 52283 4,7k 5% 0,5W
3510 4822 116 52283 4,7k 5% 0,5W
0,5W
0,5W
RESISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
3511 4822 116 52263 2,7k 5%
3512 4822 116 52263 2,7k 5%
3513 4822 116 83884 47k 5% 0,16W
3514 4822 116 83884 47k 5% 0,16W
3515 4822 116 52175 100 5% 0,5W
3527 4822 116 52256 2,2k 5% 0,16W
3532 4822 116 83874 220k 5% 0,5W
3533 4822 116 52191 33 5% 0,5W
3534 4822 050 21003 10k 1% 0,6W
3535 4822 116 52289 5,6k 5% 0,16W
3537 4822 116 83872 220 5% 0,5W
3538 4822 116 83872 220 5% 0,5W
3539 4822 050 11002 1k 5% 0,2W
3540 4822 050 11002 1k 5% 0,2W
3541 4822 050 11002 1k 5% 0,2W
3542 4822 050 11002 1k 5% 0,2W
3543 4822 050 11002 1k 5% 0,2W
3544 4822 050 11002 1k 5% 0,2W
3545 4822 050 11002 1k 5% 0,2W
3547 4822 050 11002 1k 5% 0,2W
3548 4822 116 52256 2,2k 5% 0,16W
4822 116 52256 2,2k 0,16W
4822 116 52256 2,2k 0,16W
3550 5%
3552 5%
3553 4822 116 52257 22k 5% 0,5W
3556 4822 116 52119 68 5% 0,5W
3557 4822 052 10688 6,8 5% 0,33W
DIODES
–––––––––––––––––––––––––––––––––––––––––––––––––––––
COIL
–––––––––––––––––––––––––––––––––––––––––––––––––––––
6250 4822 130 34379 BZX79-C27
5801 4822 156 31058
6251 4822 130 34174 BZX79-B4V7
6252 4822 130 31878 1N4003G
6253 4822 130 31878 1N4003G
6254 4822 130 31878 1N4003G
6255 4822 130 31878 1N4003G
6256 4822 130 31878 1N4003G
6257 4822 130 31878 1N4003G
6258 4822 130 31878 1N4003G
6259 4822 130 31981 BZX79-C3V9
6260 4822 130 31878 1N4003G
6500 4822 130 30621 1N4148
TRANSISTORS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7250 4822 130 41327 BC327-40
7252 5322 130 60068 BC558C
7500 4822 130 41327 BC327-40
7501 5322 130 60068 BC558C
7504 4822 130 44568 BC557B
7507 4822 130 41344 BC337-40
7508 4822 130 41344 BC337-40
7509 4822 130 41344 BC337-40
7510 4822 130 41344 BC337-40
INTEGRATED CIRCUITS
–––––––––––––––––––––––––––––––––––––––––––––––––––––
7251 4822 209 80817 L7805CV 5V REGULATOR
7502 4822 209 33252 TDA1549T/N1 DAC
7505 4822 209 83274 NJM4560D
7511 5322 209 11323 74HCU04N
DUAL OP. AMP
ELECTRICAL PARTSLIST AF BOARD
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
