Marantz CD6002/F - 10. Exploded View and Parts List

37
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
1F B ns
p
00M24AW251010 BADGE NEW MZ BADGE CGB1A117
1F N ns
p
00M24AW251010 BADGE NEW MZ BADGE CGB1A117
1
/
K1G ns
p
00M24AW251010 BADGE NEW MZ BADGE CGB1A117
1
/
N1B 00M24AW251010 00M24AW251010 BADGE NEW MZ BADGE CGB1A117
1
/
N1S 00M24AW251020 00M24AW251020 BADGE NEW MZ BADGE SILVER CGB1A117G
2F B ns
p
00M30CW053010 ESCUTCHEON ORNAMENT DOOR BLACK CGR1A427ZH10
2F N ns
p
00M30CW053110 ESCUTCHEON ORNAMENT DOOR GOLD CGR1A427RFYH40
2
/
K1G ns
p
00M30CW053110 ESCUTCHEON ORNAMENT DOOR GOLD CGR1A427RFYH40
2
/
N1B 00M30CW053010 00M30CW053010 ESCUTCHEON ORNAMENT DOOR BLACK CGR1A427ZH10
2
/
N1S 00M30CW053210 00M30CW053210 ESCUTCHEON ORNAMENT DOOR SILVER CGR1A427R6YH51
3F B ns
p
00M30CW158010 WINDOW WINDOW BLACK/GOLD CGU1A405Z
3F N ns
p
00M30CW158010 WINDOW WINDOW BLACK/GOLD CGU1A405Z
3
/
K1G ns
p
00M30CW158010 WINDOW WINDOW BLACK/GOLD CGU1A405Z
3
/
N1B 00M30CW158010 00M30CW158010 WINDOW WINDOW BLACK/GOLD CGU1A405Z
3
/
N1S 00M30CW158210 00M30CW158210 WINDOW WINDOW SILVER CGU1A405Y
4F B ns
p
00M30CW053020 ESCUTCHEON ORNAMENT KNOB BLACK CGR1A428ZH10
4F N ns
p
00M30CW053120 ESCUTCHEON ORNAMENT KNOB GOLD CGR1A428RFYH40
4
/
K1G ns
p
00M30CW053120 ESCUTCHEON ORNAMENT KNOB GOLD CGR1A428RFYH40
4
/
N1B 00M30CW053020 00M30CW053020 ESCUTCHEON ORNAMENT KNOB BLACK CGR1A428ZH10
4
/
N1S 00M30CW053220 00M30CW053220 ESCUTCHEON ORNAMENT KNOB SILVER CGR1A428R6YH51
5F B ns
p
00M24AW154010 KNOB KNOB LEVEL BLACK CBN1A170 CBN1A170K92
5F N ns
p
00M24AW154110 KNOB KNOB LEVEL GOLD CBN1A170 CBN1A170RFD4
5
/
K1G ns
p
00M24AW154110 KNOB KNOB LEVEL GOLD CBN1A170 CBN1A170RFD4
5
/
N1B 00M24AW154010 00M24AW154010 KNOB KNOB LEVEL BLACK CBN1A170 CBN1A170K92
5
/
N1S 00M24AW154210 00M24AW154210 KNOB KNOB LEVEL SILVER CBN1A170 CBN1A170R6G13
6F B ns
p
00M30CW248010 PANEL FRONT AL PANEL CKM1A185ZC23
6F N ns
p
00M30CW248110 PANEL FRONT AL PANEL CKM1A185YC24
6
/
K1G ns
p
00M30CW248110 PANEL FRONT AL PANEL CKM1A185YC24
6
/
N1B 00M30CW248010 00M30CW248010 PANEL FRONT AL PANEL CKM1A185ZC23
6
/
N1S 00M30CW248210 00M30CW248210 PANEL FRONT AL PANEL CKM1A185YC40
7F B ns
p
00M30CW105020 CHASSIS PANEL SUB BLACK CGW2A410R4K92
7F N ns
p
00M30CW105120 CHASSIS PANEL SUB GOLD CGW2A410RFD4
7
/
K1G ns
p
00M30CW105120 CHASSIS PANEL SUB GOLD CGW2A410RFD4
7
/
N1B 00M30CW105020 00M30CW105020 CHASSIS PANEL SUB BLACK CGW2A410R4K92
7
/
N1S 00M30CW105220 00M30CW105220 CHASSIS PANEL SUB SILVER CGW2A410R6G13
8 00M24AW355010 00M24AW355010 LENS STANDBY CGL1A183
9F B ns
p
00M24AW270010 BUTTON KNOB POWER BLACK CBT1A878 CBT1A878K92
9F N ns
p
00M24AW270110 BUTTON KNOB POWER GOLD CBT1A878 CBT1A878RFD4
9
/
K1G ns
p
00M24AW270110 BUTTON KNOB POWER GOLD CBT1A878 CBT1A878RFD4
9
/
N1B 00M24AW270010 00M24AW270010 BUTTON KNOB POWER BLACK CBT1A878 CBT1A878K92
9
/
N1S 00M24AW270210 00M24AW270210 BUTTON KNOB POWER SILVER CBT1A878 CBT1A878R6G13
10 ns
p
ns
p
PWB ASSY TACT SW PWB ASSY COP11984B
11 F B ns
p
00M30CW270010 BUTTON KNOB PLAY BLACK CBT1A1049C67
11 F N ns
p
00M30CW270110 BUTTON KNOB PLAY GOLD CBT1A1049C68
11
/
K1G ns
p
00M30CW270110 BUTTON KNOB PLAY GOLD CBT1A1049C68
11
/
N1B 00M30CW270010 00M30CW270010 BUTTON KNOB PLAY BLACK CBT1A1049C67
11
/
N1S 00M30CW270210 00M30CW270210 BUTTON KNOB PLAY SILVER CBT1A1049C22
12 ns
p
ns
p
SHEET SHEET LED CGX1A372Z
13 ns
p
ns
p
SHEET SHEET INDICATOR CGX1A386Z
14 F B ns
p
00M45BW270020 BUTTON KNOB SKIP BLACK CBT1A996K92
14 F N ns
p
00M45BW270120 BUTTON KNOB SKIP GOLD CBT1A996RFD4
14
/
K1G ns
p
00M45BW270120 BUTTON KNOB SKIP GOLD CBT1A996RFD4
14
/
N1B 00M45BW270020 00M45BW270020 BUTTON KNOB SKIP BLACK CBT1A996K92
14
/
N1S 00M45BW270220 00M45BW270220 BUTTON KNOB SKIP SILVER CBT1A996R6G13
15 F B ns
p
ns
p
PWB ASSY HEADPHONE PWB ASSY COP11983C
15 F N ns
p
ns
p
PWB ASSY HEADPHONE PWB ASSY COP11983C
15
/
K1G ns
p
ns
p
PWB ASSY HEADPHONE PWB ASSY COP11983B
15
/
N1B ns
p
ns
p
PWB ASSY HEADPHONE PWB ASSY COP11983B
15
/
N1S ns
p
ns
p
PWB ASSY HEADPHONE PWB ASSY COP11983D
17 ns
p
ns
p
PWB ASSY FRONT PWB ASSY COP11984B
18 ns
p
ns
p
BUFFER BUFFER CHG2A185
20 00M24AW304510 00M24AW304510 MECHANISM MECHA LOADER AND TRAVERSE CJDKSL2130CCMZ
21 ns
p
ns
p
CHASSIS BOTTOM CHASSIS CUA2A231
22 F B ns
p
00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
22 F N ns
p
00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
22
/
K1G ns
p
00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
22
/
N1B 00M243W057010 00M243W057010 LEG LEG GOLD/BLACK CKL2A042H11
POS. NO.
