Marantz CD6002/F - CD Mechanism (Loader Assy)

39
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
A1 90M24AW304600 90M24AW304600 MECHANISM CD MECHA.S.K.D WSL-2130CCM
1ns
p
ns
p
TRAY TRAY
(
C
)
9A07979600
2ns
p
ns
p
-- -
3ns
p
ns
p
COVER GEAR COVER
(
S
)
9A07979700
4ns
p
ns
p
GEAR TRAY GEAR
(
S
)
9A07268500
5ns
p
ns
p
RETAINER CHUCKING PLATE 9A07268900
6ns
p
ns
p
SCREW SCREW+PTPWH 2.6X7 9A07269900
7ns
p
ns
p
CLAMPER YOKE
(
S
)
, CHUCKING 9A06965300
8ns
p
ns
p
MAGNET MAGNET 9A06965400
9ns
p
ns
p
DAMPER DAMPER 9A07268700
10 ns
p
ns
p
PULLY CHUCKING PULLY 9A07979800
11 ns
p
ns
p
CHASSIS SUB CHASSIS 2130 9A07979900
12 ns
p
ns
p
SPRING COIL SPRING
(
FRONT
)
9A07980000
13 ns
p
ns
p
SPRING COIL SPRING
(
BACK
)
9A07980100
14 ns
p
ns
p
WASHER WASHER 2130 9A07980200
15 ns
p
ns
p
SCREW SCREW+P2.6X10 9A07980300
16 90M24AW259010 90M24AW259010 INSULATOR INSULATOR 9A07980400
17 90M24AW304010 90M24AW304010 MECHANISM MD ASS'Y
(
KSS-213CCM
)
9A07980500
18 ns
p
ns
p
CHASSIS OUTSERT MAIN CHASSIS
(
S
)
9A07980600
19 ns
p
ns
p
SCREW SCREW+PTPWH2.6X16 9A06966200
20 ns
p
ns
p
GEAR DRIVE GEAR
(
S
)
9A07980700
21 ns
p
ns
p
CAM CONTROL CAM
(
S
)
9A07269000
22 ns
p
ns
p
SW LEAF SW 9A07268000
23 ns
p
ns
p
CONN. PIN,CONNECTOR 5P 9A06966600
24 ns
p
ns
p
PWB PC BOARD,LOADING 9A06966700
25 ns
p
ns
p
MOTOR MOTOR ASSY LOADING 9A06966800
26 ns
p
ns
p
GEAR MIDWAY GEAR
(
S
)
9A07980800
27 ns
p
ns
p
PULLY LOADING PULLY 9A07268600
28 90M24AW264010 90M24AW264010 BELT LM BELT 9A07980900
29 ns
p
ns
p
SCREW SCREW+B2.6X2.5 9A06967200
CD MECHANISM (LOADER ASS'Y)
