Marantz CD6002/F - Page 47

55
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MAIN C501 ns
p
00MDD95270300 CER. CAP. 27PF 50V JA CCUS1H270JA
MAIN C502 ns
p
00MDD95270300 CER. CAP. 27PF 50V JA CCUS1H270JA
MAIN C503 ns
p
90M-DK900090R CER. CAP. 1UF 10V KC CCUS1A105KC
MAIN C504 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C506 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C507 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C508 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C509 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C510 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C511 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C512 ns
p
00MDK96103300 CER. CAP. 0.01UF 50V KC CCUS1H103KC
MAIN C513 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C514 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C515 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C516 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C517 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C601 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V PP CCMP2A182JN09T
MAIN C602 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J 330PF
(
TP
)
100V PP CCMP2A331JN09T
MAIN C603 00MOF15121540 00MOF15121540 FILM CAP. 120PF J 100V APSV CCMP2A121JN09T
MAIN C604 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
MAIN C605 00MOF15681540 00MOF15681540 FILM CAP. APSV 680PF J CCMP2A681JN09T
MAIN C607 ns
p
00MOA227025R0 ELECT CAP. 220UF/25V 10X20 CCEA1EROA221T
MAIN C608 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
CCEA1CR221T
MAIN C609 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
CCEA1CR221T
MAIN C701 00MOF15182540 00MOF15182540 FILM CAP. APSV 182J 1800PF
(
TP
)
100V PP CCMP2A182JN09T
MAIN C702 00MOF15331540 00MOF15331540 FILM CAP. APSV 331J 330PF
(
TP
)
100V PP CCMP2A331JN09T
MAIN C703 00MOF15121540 00MOF15121540 FILM CAP. 120PF J 100V APSV CCMP2A121JN09T
MAIN C704 ns
p
ns
p
CER. CAP. 47PF 50V J HCBS1H470JT
MAIN C705 00MOF15681540 00MOF15681540 FILM CAP. APSV 680PF J CCMP2A681JN09T
MAIN C707 ns
p
00MOA227025R0 ELECT CAP. 220UF/25V 10X20 CCEA1EROA221T
MAIN C708 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
CCEA1CR221T
MAIN C709 ns
p
00MOA227016Z0 ELECT CAP. ROS-16V 221M-H5#PE-T2
(
220UF 16V
)
CCEA1CR221T
MAIN C901 ns
p
ns
p
FILM CAP. 0.1UF 100V CCUMT2A104KB
MAIN C902 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
MAIN C903 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
MAIN C906 ns
p
ns
p
CER. CAP. 0.1UF 50V Z HCBS1H104ZFT
MAIN C909 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C911 ns
p
ns
p
CER. CAP. 0.022UF 50V Z HCBS1H223ZFT
MAIN C913 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C914 ns
p
00MDK96104300 CER. CAP. 0.1UF 50V K CCUS1H104KC
MAIN C920 ns
p
00MOA22706320 ELECT CAP. 220UF 63V CCEA1JH221E
MAIN C921 ns
p
00MOA22505020 ELECT CAP. 2.2UF 50V CCEA1HH2R2T
MAIN C922 ns
p
00MOA10605020 ELECT CAP. 10UF 50V CCEA1HH100T
MAIN C923 ns
p
90M-OA000620R ELECT CAP. KR3 25V/6800UF 18X35 CCEA1EH682E
MAIN C924 ns
p
00MOA22801620 ELECT CAP. 2200UF 16V CCEA1CH222E
MAIN C925 ns
p
00MOA10801620 ELECT CAP. 1000UF 16V CCEA1CH102E
MAIN C926 ns
p
00MOA33802520 ELECT CAP. 3300UF 25V CCEA1EH332E
MAIN C928 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C929 ns
p
00MOA10803520 ELECT CAP. 1000UF 35V CCEA1VH102E
MAIN C930 ns
p
00MOA10505020 ELECT CAP. 1UF 50V CCEA1HH1R0T
MAIN C931 ns
p
00MOA47505020 ELECT CAP. 4.7UF 50V CCEA1HH4R7T
MAIN C932 00MOB10803570 00MOB10803570 ELECT CAP. 1000U 35V
(
ALP
)(
LF
)
-BLOCK CAP CCEA1VLAO102E
MAIN C933 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C934 ns
p
00MOA47701620 ELECT CAP. 470UF 16V ZF CCEA1CH471T
MAIN C935 00MOB10803570 00MOB10803570 ELECT CAP. 1000U 35V
(
ALP
)(
LF
)
-BLOCK CAP CCEA1VLAO102E
MAIN C936 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C937 ns
p
00MOA47701620 ELECT CAP. 470UF 16V ZF CCEA1CH471T
MAIN C938 ns
p
00MOA10801620 ELECT CAP. 1000UF 16V CCEA1CH102E
MAIN C939 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C940 ns
p
00MOA47701620 ELECT CAP. 470UF 16V ZF CCEA1CH471T
MAIN C941 ns
p
00MOA10701620 ELECT CAP. 100UF 16V CCEA1CH101T
MAIN C942 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN C943 ns
p
00MOA47602520 ELECT CAP. 47UF 25V CCEA1EH470T
MAIN CN31 ns
p
ns
p
CONN. 5P STRAIGHT CJP05GA19ZY
MAIN CN32 ns
p
ns
p
CONN. 6P STRAIGHT CJP06GA19ZY
MAIN CN33 ns
p
ns
p
CONN. 16P WAFER CARD CABLE CJP16GA117ZY
MAIN CN51 ns
p
ns
p
CONN. 15P FFC WAFER CJP15GA117ZY
