Marantz CD6002/F - Page 49

57
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
MAIN IC33 90M-HC700550R 90M-HC700550R IC TC74HCU04AFNG HVI74HCU04AFNG
MAIN IC41 90M-HC109330R 90M-HC109330R IC CS4398CZ HVICS4398CZ
MAIN IC45 00MHC008005K0 00MHC008005K0 IC TC7WHU04FU
(
TE12 CVITC7WHU04FU
MAIN IC46 00MHC007905K0 00MHC007905K0 IC TC7WH74FU
(
TE12L CVITC7WH74FU
MAIN IC47 90M-HC109440R 90M-HC109440R IC BU2630FV BVIBU2630FV-E2
MAIN IC48 90M-HC700560R 90M-HC700560R IC TC74LS628 HVITC74LS628
MAIN IC49 00MHC009105K0 00MHC009105K0 IC TC7WH157FU HVITC7WH157FU
MAIN IC50 00MHC008005K0 00MHC008005K0 IC TC7WHU04FU
(
TE12 CVITC7WHU04FU
MAIN IC51 90M-HS30CWX0R 90M-HS30CWX0R U-PRO T5CD2
(
F AAD JZ
)
CD6002 CVIT5CD2
MAIN IC52 90M-HC110070R 90M-HC110070R IC S61C256AH12J 256K SRAM BVIS61C256AH12J
MAIN IC53 00MHC10099540 00MHC10099540 IC S-80145ALMC HVIS-80145ALMC
MAIN IC91 90M-HC300950R 90M-HC300950R IC KIA78R08 REGULATOR
(
TO220IS-4
)
CVIKIA78R08PI
MAIN IC92 00MHC3890599F 00MHC3890599F IC KIA7805API HVIKIA7805API
MAIN IC93 90M-HC300960R 90M-HC300960R IC KIA78D33 REGULATOR
(
TO220IS-4
)
CVIKIA78D33PI
MAIN IC94 00MHC3890599F 00MHC3890599F IC KIA7805API HVIKIA7805API
MAIN IC95 90M-HC900150R 90M-HC900150R IC KIA1117S/F33 REGULATOR
(
SOT-223
)
CVIKIA1117S33
MAIN IC96 90M-HC900160R 90M-HC900160R IC LM1117S15 REGULATOR
(
SOT-223
)
CVIKIA1117S15
MAIN JK31 90M-YT005310R 90M-YT005310R OPT. CONN. TOTX177L HJSTOTX177L
MAIN JK32 90M-YT003100R 90M-YT003100R TERMINAL CINCH 1P
(
GOLD
)
COAXIAL CJJ4M045Z
MAIN JK33 90M-YT003120R 90M-YT003120R TERMINAL CINCH 2P
(
GOLD
)
REMOTE CJJ4N036Z
MAIN JK61 90M-YT005350R 90M-YT005350R TERMINAL 1P CINCH RED GOLD PLATE CJJ4M060Z
MAIN JK71 90M-YT005360R 90M-YT005360R TERMINAL 1P CINCH WHITE GOLD PLATE CJJ4M059Z
MAIN L301 ns
p
ns
p
CHIP INDACT FI-C3216-103KJT HLQ09E100KRZ
MAIN L303 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN L304 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN L305 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN L371 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN L401 ns
p
ns
p
CHIP INDACT FI-C3216-103KJT HLQ09E100KRZ
MAIN L451 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN L452 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN L901 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN L902 90M-FN000260R 90M-FN000260R EMI FILTER HU-1H3216-121 HLZ91002Z
MAIN Q301 90M-HX600020R 90M-HX600020R CHIP TRS. KTA1504S Y RTK HVTKTA1504SYRTK
MAIN Q374 90M-HX800100R 90M-HX800100R CHIP TRS. KTC3875S Y RTK HVTKTC3875SYRTK
MAIN Q502 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
MAIN Q503 90M-HX600010R 90M-HX600010R CHIP TRS. KRA102S HVTKRA102S
MAIN Q601 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4W HVT2SK369BLT
MAIN Q602 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q603 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4W HVT2SK369BLT
MAIN Q604 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q605 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q606 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q607 00MHF201701G0 00MHF201701G0 F.E.T. 2SK170 BL VGDS=-40V PD=0.4V HVT2SK170BLT
MAIN Q608 00MHF100741G0 00MHF100741G0 F.E.T. 2SJ74BLT HVT2SJ74BLT
MAIN Q609 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q610 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q611 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q612 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q613 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q614 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q615 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q616 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q617 90M-HX800080R 90M-HX800080R CHIP TRS. KRC107S HVTKRC107S
MAIN Q618 00D2690191903 00D2690191903 CHIP TRS. KRA104S HVTKRA104S
MAIN Q619 90M-HT300970R 90M-HT300970R TRS. KTC2875B HVTKTC2875B
MAIN Q620 90M-HT300970R 90M-HT300970R TRS. KTC2875B HVTKTC2875B
MAIN Q701 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4W HVT2SK369BLT
MAIN Q702 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q703 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4W HVT2SK369BLT
MAIN Q704 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q705 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q706 00MHT800931A0 00MHT800931A0 TRS. KTC3200GR HVTKTC3200GRT
MAIN Q707 00MHF201701G0 00MHF201701G0 F.E.T. 2SK170 BL VGDS=-40V PD=0.4V HVT2SK170BLT
MAIN Q708 00MHF100741G0 00MHF100741G0 F.E.T. 2SJ74BLT HVT2SJ74BLT
MAIN Q709 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q710 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
MAIN Q711 00MHT600121A0 00MHT600121A0 TRS. KTA1268GR HVTKTA1268GRT
