Marantz CD6002/F - Page 53

61
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P.C.B.
NAME
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MZ
)
PART NAME DESCRIPTION
POS. NO.
POWER T951 F N ns
p
90M-TS003150R TRANSF. # TRANSF. POWER CD6002 100V/50H
Z
CLT5N035ZJ
POWER T951
/
K1G ns
p
90M-TS003160R TRANSF. # TRANSF. POWER CD6002 230V/50H
Z
CLT5N035ZE
POWER T951
/
N1B 90M-TS003160R 90M-TS003160R TRANSF. # TRANSF. POWER CD6002 230V/50H
Z
CLT5N035ZE
POWER T951
/
N1S 90M-TS003160R 90M-TS003160R TRANSF. # TRANSF. POWER CD6002 230V/50H
Z
CLT5N035ZE
POWER T952 F B ns
p
90M-TS003170R TRANSF. # TRANSF. SUB CD6002/F CLT5I009ZJ
POWER T952 F N ns
p
90M-TS003170R TRANSF. # TRANSF. SUB CD6002/F CLT5I009ZJ
POWER T952
/
K1G ns
p
90M-TS003180R TRANSF. # TRANSF. SUB CD6002/N CLT5I009ZE
POWER T952
/
N1B 90M-TS003180R 90M-TS003180R TRANSF. # TRANSF. SUB CD6002/N CLT5I009ZE
POWER T952
/
N1S 90M-TS003180R 90M-TS003180R TRANSF. # TRANSF. SUB CD6002/N CLT5I009ZE
TACT SW PWB
(
CUP11984-2
)
TACT CN22 ns
p
ns
p
CONN. 5P WAFER CJP05GB46ZY
TACT D201 90M-HI101120R 90M-HI101120R LED SLR325VRA47 KVDSLR325VRA47
TACT Q201 90M-BA001460R 90M-BA001460R TRS. KRC107M HVTKRC107MT
TACT R201 ns
p
ns
p
RES. 1.5K OHM 1/5W J CRD20TJ152T
TACT R202 ns
p
ns
p
RES. 10K OHM 1/5W J CRD20TJ103T
TACT S201 90M-SP001400R 90M-SP001400R PUSH SW TACT SW EVQ22505R CST1A023ZT
