Marantz DV9500 - Page 136

134
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P801 C855 /U1B ns
p
00MOA22702550 ELECT. CAP. 220UF M 25 V AR
A
P801 C856 /F1B ns
p
00MOA22702550 ELECT. CAP. 220UF M 25 V AR
A
P801 C856 /F1N ns
p
00MOA22702550 ELECT. CAP. 220UF M 25 V AR
A
P801 C856 /L1G ns
p
00MOA22702550 ELECT. CAP. 220UF M 25 V AR
A
P801 C856 /N1B ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
P801 C856 /N1S ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
P801 C856 /S1G ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
P801 C856 /U1B ns
p
00MOA22702550 ELECT. CAP. 220UF M 25 V AR
A
P801 C861 ns
p
00MOA22801620 ELECT. CAP. 2200UF 16V
P801 C862 ns
p
00MOA22701020 ELECT. CAP. 220 UF M 10V RA-2
P801 C863 ns
p
00MOA10701020 ELECT. CAP. 100 UF M 10V RA-2
P801 C871 ns
p
00MOA10802520 ELECT. CAP. 1000 UF M 25V RA-2
P801 C872 ns
p
00MOA10405020 ELECT. CAP. 0.1 UF M 50V RA-2
P801 C873 ns
p
00MOA10606320 ELECT. CAP. 10 UF M 63V RA-2
P801 D801 00MHD20031290 00MHD20031290 DIODE ! S1WB
(
A
)
60 30A 600
V
P801 D802 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D803 00MHD32201000 00MHD32201000 ZENER DIODE 22V ZENER EQUIVALENT
P801 D804 00MHD20049080 00MHD20049080 DIODE ! AG01 400V 0.7
A
P801 D805 00MHD31801000 00MHD31801000 ZENER DIODE 18V ZENER EQUIVALENT
P801 D806 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
P801 D807 00MHD20049080 00MHD20049080 DIODE ! AG01 400V 0.7
A
P801 D808 00MHD32001000 00MHD32001000 ZENER DIODE 20V ZENER EQUIVALENT
P801 D810 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
P801 D811 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D812 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D814 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D815 00MHD20050080 00MHD20050080 DIODE ! RK46
(
SBD
)
60V 3.5
A
P801 D817 00MHD20053080 00MHD20053080 DIODE ! EK19 90V 1.5
A
P801 D818 00MHD32001000 00MHD32001000 ZENER DIODE 20V ZENER EQUIVALENT
P801 D819 00MHD30911000 00MHD30911000 ZENER DIODE 9.1V ZENER EQUIVALENT
P801 D841 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D845 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D851 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D852 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D853 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D854 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D855 00MHD31001000 00MHD31001000 ZENER DIODE 10V ZENER EQUIVALENT
P801 D856 00MHD31001000 00MHD31001000 ZENER DIODE 10V ZENER EQUIVALENT
P801 D857 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D858 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 D861 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D862 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D863 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D864 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D871 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D872 00MHD20055100 00MHD20055100 DIODE ! SHOTTKY 11EQS10 1A 100
V
P801 D873 ns
p
00MHD20055100 DIODE SHOTTKY 11EQS10 1A 100
V
P801 D875 ns
p
00MHD20002000 DIODE 1SS176,MA165,1SS254 30V 0.1
A
P801 F801 00MFS20250200 00MFS20250200 FUSE # T2.5A/250V TR5 NO.19372
(
TP
)
P801 F802 00MFS20025200 00MFS20025200 FUSE # T250MA/250V TR5 NO.19372
(
TP
)
P801 F803 00MFS20315200 00MFS20315200 FUSE # FUSE 3.15A 250V SEMKO VDE
P801 F851 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 F852 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 F853 00MFS20050200 00MFS20050200 FUSE # T500MA/250V TR5 NO.19372
(
TP
)
P801 L801 00MLC22260130 00MLC22260130 CHOKE COIL # 22MH X2 LINE FILTER
P801 L803 00MLC14734500 00MLC14734500 CHOKE COIL RCH-110 47UH 2.5
A
P801 L804 00MFC90050130 00MFC90050130 FERRITE CORE BL02RN2-R62T2 FERRITE BEAD
P801 L841 00MLY10060010 00MLY10060010 RELAY # SDT-S-106LMR TV-5 DC6V 250M
W
P801 Q801 00MHF22943000 00MHF22943000 F.E.T. ! 2SK2943 900V 3
A
P801 Q802 00MHC10007130 00MHC10007130 IC FA3647P PWM CONTROL IC
P801 Q803 00MHW10032320 00MHW10032320 PHOTO UNIT ! PC-123F2 PHOTO COUPLER
P801 Q804 00MHC33036590 00MHC33036590 IC TL431CZ PROG.VOLTAGE REFERENCE
P801 Q806 00MHC10006080 00MHC10006080 IC ! SI-3050C +5V 1.5A WITH S
W
P801 Q807 00MHC10006080 00MHC10006080 IC ! SI-3050C +5V 1.5A WITH S
W
P801 Q808 00MHC3691208F 00MHC3691208F IC ! SI-3120F +12V 1A WITH S
W
P801 Q809 00MHT316272B0 00MHT316272B0 TRANSISTOR 2SC1627 O,Y 80V 300MA 600MW T
O
P801 Q812 00MHC3890809F 00MHC3890809F IC ! +8V 1A REGULATOR NJM7808F
A
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
