NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P801 Q813 00MHT30001000 00MHT30001000 TRANSISTOR C2458,C1740S,C3199,ETC.
P801 Q814 00MHT316272B0 00MHT316272B0 TRANSISTOR 2SC1627 O,Y 80V 300MA 600MW T
O
P801 Q841 00MHT10001000 00MHT10001000 TRANSISTOR ! A1048,A933S,A1267,ETC.
P801 Q842 00MBA20001000 00MBA20001000 SEMICON.COMP DTC114ES/UN4211 10K,10
K
P801 Q853 00MHT41415100 00MHT41415100 TRANSISTOR ! 2SD1415
A
P801 Q854 00MHT21020100 00MHT21020100 TRANSISTOR ! 2SB1020
A
P801 Q861 00MHC3690521F 00MHC3690521F IC ! BA05T 5V/1
A
P801 Q862 00MHC36J3321F 00MHC36J3321F IC ! BA033T
P801 Q871 00MHT30001000 00MHT30001000 TRANSISTOR C2458,C1740S,C3199,ETC.
P801 Q872 00MHT30001000 00MHT30001000 TRANSISTOR C2458,C1740S,C3199,ETC.
P801 Q874 00MHT10001000 00MHT10001000 TRANSISTOR A1048,A933S,A1267,ETC.
P801 Q875 00MBA20004000 00MBA20004000 SEMICON.COMP DTC114TS/UN4215 10
K
P801 R801 /F1B ns
p
00MRC10225820 RESISTOR ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R801 /F1N ns
p
00MRC10225820 RESISTOR ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R801 /L1G ns
p
00MRC10225820 RESISTOR ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R801 /N1B 00MRC05105010 00MRC05105010 RESISTOR ! 1M OHM +-5% 1W RCR60 L15
P801 R801 /N1S 00MRC05105010 00MRC05105010 RESISTOR ! 1M OHM +-5% 1W RCR60 L15
P801 R801 /S1G ns
p
00MRC05105010 RESISTOR ! 1M OHM +-5% 1W RCR60 L15
P801 R801 /U1B ns
p
00MRC10225820 RESISTOR ! 2.2M OHM +- 10% 1/2W FOR U
L
P801 R802 /F1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R802 /F1N ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R802 /L1G ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R802 /N1B ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R802 /N1S ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R802 /S1G ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R802 /U1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R803 /F1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R803 /F1N ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R803 /L1G ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R803 /N1B ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R803 /N1S ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R803 /S1G ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R803 /U1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R804 /F1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R804 /F1N ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R804 /L1G ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R804 /N1B ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R804 /N1S ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R804 /S1G ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R804 /U1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R805 /F1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R805 /F1N ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R805 /L1G ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R805 /N1B ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R805 /N1S ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R805 /S1G ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R805 /U1B ns
p
00MGD05224160 RESISTOR 220K OHM +- 5% 1/6
W
P801 R806 ns
p
00MGD05680160 RESISTOR 68 OHM +- 5% 1/6
W
P801 R807 ns
p
00MGD05103160 RESISTOR 10K OHM +- 5% 1/6
W
P801 R808 ns
p
00MGD05100160 RESISTOR 10 OHM +- 5% 1/6
W
P801 R809 00MNK05470010 00MNK05470010 METAL RESISTOR 47 OHM +- 5% 1
W
P801 R810 ns
p
00MGD05124160 RESISTOR 120K OHM +- 5% 1/6
W
P801 R811 00MNK05100010 00MNK05100010 METAL RESISTOR 10 OHM +- 5% 1
W
P801 R812 00MNL05222020 00MNL05222020 METAL RESISTOR 0.22 OHM +- 5% 2
W
P801 R813 /F1B ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R813 /F1N ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R813 /L1G ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R813 /N1B ns
p
00MGD05274160 RESISTOR 270K OHM +- 5% 1/6
W
P801 R813 /N1S ns
p
00MGD05274160 RESISTOR 270K OHM +- 5% 1/6
W
P801 R813 /S1G ns
p
00MGD05274160 RESISTOR 270K OHM +- 5% 1/6
W
P801 R813 /U1B ns
p
00MGD05334160 RESISTOR 330K OHM +- 5% 1/6
W
P801 R814 ns
p
00MGD05563160 RESISTOR 56K OHM +- 5% 1/6
W
P801 R815 ns
p
00MGD05101160 RESISTOR 100 OHM +- 5% 1/6
W
P801 R816 ns
p
00MGD05151160 RESISTOR 150 OHM +- 5% 1/6
W
P801 R817 ns
p
00MGD05221160 RESISTOR 220 OHM +- 5% 1/6
W
P801 R818 ns
p
00MGD05471160 RESISTOR 470 OHM +- 5% 1/6
W
P801 R819 ns
p
00MGD05102160 RESISTOR 1K OHM +- 5% 1/6
W
