Marantz DV9500 - Page 138

136
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
P801 R820 ns
p
00MGD05332160 RESISTOR 3.3K OHM +- 5% 1/6
W
P801 R825 ns
p
00MGD05472160 RESISTOR 4.7K OHM +- 5% 1/6
W
P801 R826 ns
p
00MGD05681160 RESISTOR 680 OHM +- 5% 1/6
W
P801 R827 ns
p
00MGD05103160 RESISTOR 10K OHM +- 5% 1/6
W
P801 R828 ns
p
00MGD05472160 RESISTOR 4.7K OHM +- 5% 1/6
W
P801 R829 ns
p
00MGD05033160 RESISTOR 3.3 OHM +- 5% 1/6
W
P801 R830 ns
p
00MGD05681160 RESISTOR 680 OHM +- 5% 1/6
W
P801 R831 ns
p
00MGD05103160 RESISTOR 10K OHM +- 5% 1/6
W
P801 R841 ns
p
00MGD05473160 RESISTOR 47K OHM +- 5% 1/6
W
P801 R842 ns
p
00MGD05472160 RESISTOR 4.7K OHM +- 5% 1/6
W
P801 R843 ns
p
00MGD05223160 RESISTOR 22K OHM +- 5% 1/6
W
P801 R851 ns
p
00MGD05102160 RESISTOR 1K OHM +- 5% 1/6
W
P801 R852 ns
p
00MGD05102160 RESISTOR 1K OHM +- 5% 1/6
W
P801 R871 ns
p
00MGD05102160 RESISTOR 1K OHM +- 5% 1/6
W
P801 R872 ns
p
00MGD05123160 RESISTOR 12K OHM +- 5% 1/6
W
P801 R873 ns
p
00MGD05335160 RESISTOR 3.3M OHM +- 5% 1/6
W
P801 R874 ns
p
00MGD05473160 RESISTOR 47K OHM +- 5% 1/6
W
P801 R875 ns
p
00MGD05473160 RESISTOR 47K OHM +- 5% 1/6
W
P801 R876 ns
p
00MGD05103160 RESISTOR 10K OHM +- 5% 1/6
W
P801 R877 ns
p
00MGD05473160 RESISTOR 47K OHM +- 5% 1/6
W
P801 R879 ns
p
00MGD05332160 RESISTOR 3.3K OHM +- 5% 1/6
W
P801 T801 00MTS12900080 00MTS12900080 TRANSF. # SW TRANSF ER28S
P801 T851 /F1B ns
p
00MTS14159040 TRANSF. # PE4124 AUDIO TRANSF. AC100
V
P801 T851 /F1N ns
p
00MTS14159040 TRANSF. # PE4124 AUDIO TRANSF. AC100
V
P801 T851 /L1G ns
p
00MTS14159050 TRANSF. # PE4124 AUDIO TRANSF. AC120
V
P801 T851 /N1B 00MTS14159060 00MTS14159060 TRANSF. # PE4124 AUDIO TRANSF. AC230
V
P801 T851 /N1S 00MTS14159060 00MTS14159060 TRANSF. # PE4124 AUDIO TRANSF. AC230
V
P801 T851 /S1G ns
p
00MTS14159060 TRANSF. # PE4124 AUDIO TRANSF. AC230
V
P801 T851 /U1B ns
p
00MTS14159050 TRANSF. # PE4124 AUDIO TRANSF. AC120
V
P802 S801 00MSP01013800 00MSP01013800 PUSH SWITCH # AC POWER SWITCH ESB92S17B
PA01 CA01 ns
p
00MOA10701620 ELECT. CAP. 100 UF M 16V RA-2
PA01 CA03 00MOF55101560 00MOF55101560 FILM CAP DAMG 100PF 630
V
PA01 CA04 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CA05 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CA06 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CA08 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CA10 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CA11 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CA33 00MOF55101560 00MOF55101560 FILM CAP DAMG 100PF 630
V
PA01 CA34 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CA35 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CA36 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CA38 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CA40 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CA41 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CC03 00MOF55101560 00MOF55101560 FILM CAP DAMG 100PF 630
V
PA01 CC04 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CC05 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CC06 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CC08 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CC10 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CC11 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CC33 00MOF55101560 00MOF55101560 FILM CAP DAMG 100PF 630
V
PA01 CC34 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CC35 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CC36 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CC38 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CC40 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CC41 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CD01 /F1B ns
p
00MOA22701650 ELECT. CAP. 220UF/16V ARA CERAFINE TAPING
PA01 CD01 /F1N ns
p
00MOA22701650 ELECT. CAP. 220UF/16V ARA CERAFINE TAPING
PA01 CD01 /L1G ns
p
00MOA22701650 ELECT. CAP. 220UF/16V ARA CERAFINE TAPING
PA01 CD01 /N1B ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CD01 /N1S ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CD01 /S1G ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CD01 /U1B ns
p
00MOA22701650 ELECT. CAP. 220UF/16V ARA CERAFINE TAPING
PA01 CD02 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
