138
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PA01 CS05 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CS06 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CS08 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CS10 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CS11 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CS33 00MOF55101560 00MOF55101560 FILM CAP DAMG 100PF 630
V
PA01 CS34 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CS35 00MOF15102540 00MOF15102540 FILM CAP 1000PF J 100V APS
V
PA01 CS36 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CS38 00MOF15221540 00MOF15221540 FILM CAP APSV 221J,220PF
(
TP
)
100V PP
PA01 CS40 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 CS41 ns
p
00MOA22701640 ELECT. CAP. 220UF 16V ARS
PA01 DA01 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DA21 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DA22 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DA51 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DC21 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DC51 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DH01 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH02 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
PA01 DH11 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH12 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
PA01 DH21 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH22 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
PA01 DH31 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH32 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
PA01 DH41 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH42 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
PA01 DH51 00MHZ20007210 00MHZ20007210 CHIP DIODE IMN10 DIODE ARRAY
PA01 DH52 00MHZ20018050 00MHZ20018050 CHIP DIODE 1SS302
(
TOSHIBA
)
PA01 DS21 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 DS51 00MHZ21005000 00MHZ21005000 CHIP DIODE 1SS301,DAN202U UMT TYPE
PA01 LA01 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PA01 QA01 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V LANK TOSHIB
A
PA01 QA02 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V LANK TOSHIB
A
PA01 QA04 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QA06 /N1B 00MHX342132A0 00MHX342132A0 CHIP TR. 2SC4213
PA01 QA06 /N1S 00MHX342132A0 00MHX342132A0 CHIP TR. 2SC4213
PA01 QA07 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QA08 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QA09 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QA11 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QA12 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QA13 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QA31 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V LANK TOSHIB
A
PA01 QA32 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V LANK TOSHIB
A
PA01 QA34 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QA36 /N1B 00MHX342132A0 00MHX342132A0 CHIP TR. 2SC4213
PA01 QA36 /N1S 00MHX342132A0 00MHX342132A0 CHIP TR. 2SC4213
PA01 QA37 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QA38 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QA39 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QA73 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QC01 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V LANK TOSHIB
A
PA01 QC02 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V LANK TOSHIB
A
PA01 QC04 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QC08 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QC09 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QC31 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V LANK TOSHIB
A
PA01 QC32 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V LANK TOSHIB
A
PA01 QC34 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QC38 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QC39 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QD01 00MHC10020880 00MHC10020880 IC CS4398 192KHZ DAC
PA01 QD21 00MHC10020880 00MHC10020880 IC CS4398 192KHZ DAC
PA01 QD41 00MHC10020880 00MHC10020880 IC CS4398 192KHZ DAC
PA01 QD61 00MHC10440050 00MHC10440050 IC TC7SH08FU 932211931682
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
