Marantz DV9500 - Page 141

139
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PA01 QH01 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH02 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH03 00MHX328731B0 00MHX328731B0 CHIP TR. 2SC2873
(
Y
)
PA01 QH04 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH05 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH06 00MHX333241B0 00MHX333241B0 CHIP TR. 2SC3324
(
B
)
PA01 QH11 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH12 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH13 00MHX328731B0 00MHX328731B0 CHIP TR. 2SC2873
(
Y
)
PA01 QH14 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH15 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH16 00MHX333241B0 00MHX333241B0 CHIP TR. 2SC3324
(
B
)
PA01 QH21 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH22 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH23 00MHX328731B0 00MHX328731B0 CHIP TR. 2SC2873
(
Y
)
PA01 QH24 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH25 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH26 00MHX333241B0 00MHX333241B0 CHIP TR. 2SC3324
(
B
)
PA01 QH31 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH32 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH33 00MHX328731B0 00MHX328731B0 CHIP TR. 2SC2873
(
Y
)
PA01 QH34 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH35 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH36 00MHX333241B0 00MHX333241B0 CHIP TR. 2SC3324
(
B
)
PA01 QH41 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH42 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH43 00MHX328731B0 00MHX328731B0 CHIP TR. 2SC2873
(
Y
)
PA01 QH44 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH45 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH46 00MHX333241B0 00MHX333241B0 CHIP TR. 2SC3324
(
B
)
PA01 QH51 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH52 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
PA01 QH53 00MHX328731B0 00MHX328731B0 CHIP TR. 2SC2873
(
Y
)
PA01 QH54 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH55 00MHX113121B0 00MHX113121B0 CHIP TR. 2SA1312
(
B
)
PA01 QH56 00MHX333241B0 00MHX333241B0 CHIP TR. 2SC3324
(
B
)
PA01 QS01 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V LANK TOSHIB
A
PA01 QS02 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V LANK TOSHIB
A
PA01 QS04 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QS08 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QS09 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 QS31 00MHF201701H0 00MHF201701H0 F.E.T. 2SK170 V LANK TOSHIB
A
PA01 QS32 00MHF100741H0 00MHF100741H0 F.E.T. 2SJ74 V LANK TOSHIB
A
PA01 QS34 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PA01 QS38 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PA01 QS39 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PA01 RA01 00MNI05332110 00MNI05332110 CHIP RESISTOR 3.3K OHM +- 5% 1/10
W
PA01 RA02 00MNI05332110 00MNI05332110 CHIP RESISTOR 3.3K OHM +- 5% 1/10
W
PA01 RA03 00MNI05222110 00MNI05222110 CHIP RESISTOR 2.2K OHM +- 5% 1/10
W
PA01 RA04 00MNI05222110 00MNI05222110 CHIP RESISTOR 2.2K OHM +- 5% 1/10
W
PA01 RA05 00MNI05222110 00MNI05222110 CHIP RESISTOR 2.2K OHM +- 5% 1/10
W
PA01 RA06 00MNI05222110 00MNI05222110 CHIP RESISTOR 2.2K OHM +- 5% 1/10
W
PA01 RA07 00MNI05123110 00MNI05123110 CHIP RESISTOR 12K OHM +- 5% 1/10
W
PA01 RA08 00MNI05153110 00MNI05153110 CHIP RESISTOR 15K OHM +- 5% 1/10
W
PA01 RA09 00MNI05123110 00MNI05123110 CHIP RESISTOR 12K OHM +- 5% 1/10
W
PA01 RA10 00MNI05153110 00MNI05153110 CHIP RESISTOR 15K OHM +- 5% 1/10
W
PA01 RA13 00MNI05473110 00MNI05473110 CHIP RESISTOR 47K OHM +- 5% 1/10
W
PA01 RA14 00MNI05680110 00MNI05680110 CHIP RESISTOR 68 OHM +- 5% 1/10
W
PA01 RA15 00MNI05680110 00MNI05680110 CHIP RESISTOR 68 OHM +- 5% 1/10
W
PA01 RA16 00MNI05104110 00MNI05104110 CHIP RESISTOR 100K OHM +- 5% 1/10
W
PA01 RA17 ns
p
00MNN05224610 CHIP RESISTOR 220K OHM +- 5% 1/16
W
PA01 RA18 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PA01 RA19 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PA01 RA20 00MNI05680110 00MNI05680110 CHIP RESISTOR 68 OHM +- 5% 1/10
W
PA01 RA21 /N1B ns
p
00MNN05221610 CHIP RESISTOR 220 OHM +- 5% 1/16
W
PA01 RA21 /N1S ns
p
00MNN05221610 CHIP RESISTOR 220 OHM +- 5% 1/16
W
PA01 RA22 /N1B ns
p
00MNN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16
W
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
