Marantz DV9500 - Page 145

143
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PA01 RS49 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PA01 RS50 00MNI05680110 00MNI05680110 CHIP RESISTOR 68 OHM +- 5% 1/10
W
PA01 RS55 ns
p
00MNN05102610 CHIP RESISTOR 1K OHM +- 5% 1/16
W
PA01 RS57 ns
p
00MNN05332610 CHIP RESISTOR 3.3K OHM +- 5% 1/16
W
PA01 RS58 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PF01 CF01 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF02 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF03 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF04 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF05 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF06 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF07 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF11 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 CF12 ns
p
00MDK98473300 CERAMIC CAP. 0.047UF
PF01 CF15 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PF01 CF17 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PF01 CF22 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PF01 CF24 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PF01 CF71 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PF01 CF72 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PF01 CF73 ns
p
00MDD95270300 CERAMIC CAP. 27PF
(
GR39
)
PF01 CF74 ns
p
00MDK98473300 CERAMIC CAP. 0.047UF
PF01 CF80 ns
p
00MDK98104200 CERAMIC CAP. GRM39F104Z16 0.1UF MURAT
A
PF01 CF81 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PF01 DF31 00MHI10062320 00MHI10062320 L.E.D. LT3D8B RED 3O
PF01 DF32 00MHI10045080 00MHI10045080 L.E.D. SML11516C-TP4
PF01 LF01 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF02 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF03 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF71 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 LF72 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PF01 QF21 00MBA10026210 00MBA10026210 SEMICON.COMP DTA114EU
PF01 QF31 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF01 QF32 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF01 QF33 00MBA10026210 00MBA10026210 SEMICON.COMP DTA114EU
PF01 QF34 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF01 QF35 00MBA10026210 00MBA10026210 SEMICON.COMP DTA114EU
PF01 QF36 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PF01 QF71 00MHC10416030 00MHC10416030 IC FL DRIVER LC75712NE
PF01 QF80 00MHC007805K0 00MHC007805K0 IC TC74VHCT125AFT OUAD BUS BUFFER
PF01 RF01 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF02 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF03 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF04 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF05 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF06 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF07 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF08 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF09 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF10 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF11 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PF01 RF12 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PF01 RF21 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PF01 RF23 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PF01 RF31 ns
p
00MNN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16
W
PF01 RF32 ns
p
00MNN05272610 CHIP RESISTOR 2.7K OHM +- 5% 1/16
W
PF01 RF33 ns
p
00MNN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16
W
PF01 RF34 ns
p
00MNN05102610 CHIP RESISTOR 1K OHM +- 5% 1/16
W
PF01 RF35 ns
p
00MNN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16
W
PF01 RF36 ns
p
00MNN05272610 CHIP RESISTOR 2.7K OHM +- 5% 1/16
W
PF01 RF37 ns
p
00MNN05223610 CHIP RESISTOR 22K OHM +- 5% 1/16
W
PF01 RF38 ns
p
00MNN05332610 CHIP RESISTOR 3.3K OHM +- 5% 1/16
W
PF01 RF42 ns
p
00MNN05562610 CHIP RESISTOR 5.6K OHM +- 5% 1/16
W
PF01 RF43 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PF01 RF45 ns
p
00MNN05562610 CHIP RESISTOR 5.6K OHM +- 5% 1/16
W
PF01 RF46 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PF01 RF48 ns
p
00MNN05562610 CHIP RESISTOR 5.6K OHM +- 5% 1/16
W
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
