Marantz DV9500 - Page 146

144
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PF01 RF71 ns
p
00MNN05153610 CHIP RESISTOR 15K OHM +- 5% 1/16
W
PF01 RF72 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PF01 RF80 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PF01 SF01 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 SF02 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 SF03 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 SF04 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 SF05 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 SF06 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 SF07 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 SF08 00MSP01012030 00MSP01012030 PUSH SWITCH SKHVBF 260GF RED
PF01 VF01 00MHQ31302920 00MHQ31302920 DISPLAY VFD CH2099CB
PF01 ZF21 00MHW10004210 00MHW10004210 PHOTO UNIT RPM6936-V4
(
IR SENSOR
)
PH01 C959 ns
p
00MOA22701620 ELECT. CAP. 220 UF M 16V RA-2
PH01 C960 ns
p
00MOA22701620 ELECT. CAP. 220 UF M 16V RA-2
PH01 C961 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C962 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C963 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C964 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C965 00MDF15332350 00MDF15332350 FILM CAP. 0.0033UF,J,M,50
V
PH01 C966 00MDF15332350 00MDF15332350 FILM CAP. 0.0033UF,J,M,50
V
PH01 C967 00MDF15222350 00MDF15222350 FILM CAP. 0.0022UF,J,M,50
V
PH01 C968 00MDF15222350 00MDF15222350 FILM CAP. 0.0022UF,J,M,50
V
PH01 C969 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PH01 C970 ns
p
00MDD95101300 CERAMIC CAP. 100 PF +- 5 % CG 50V GR39
PH01 C971 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C972 ns
p
00MOA47601620 ELECT. CAP. 47 UF M 16V RA-2
PH01 C973 ns
p
00MDK96102300 CERAMIC CAP. 1000 PF +- 10 % B 50V GR36
PH01 C974 ns
p
00MDK96102300 CERAMIC CAP. 1000 PF +- 10 % B 50V GR36
PH01 J952 00MYJ01004240 00MYJ01004240 JACK HLJ2307-01-3160
PH01 L957 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 L958 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 L959 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 L960 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 L961 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 L962 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 L963 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 L964 00MFC90020200 00MFC90020200 FERRITE CORE BLM18BA121SN1
PH01 Q951 00MHC10011090 00MHC10011090 IC NJM4558M
(
Y
)
PH01 Q952 00MHC10045090 00MHC10045090 IC NJM-4556MB
PH01 Q953 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PH01 Q954 00MBA20016050 00MBA20016050 SEMICON.COMP HN1C03F
(
B
)(
NPNX2
(
MUTING
))
PH01 R954 ns
p
00MNN05104610 CHIP RESISTOR 100K OHM +- 5% 1/16
W
PH01 R955 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PH01 R956 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PH01 R957 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PH01 R958 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PH01 R959 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PH01 R960 ns
p
00MNN05272610 CHIP RESISTOR 2.7K OHM +- 5% 1/16
W
PH01 R961 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PH01 R962 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PH01 R963 ns
p
00MNN05222610 CHIP RESISTOR 2.2K OHM +- 5% 1/16
W
PH01 R964 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PH01 R965 00MRM01031220 00MRM01031220 VARIABLE RESIST RK09L12B0 10K B ALPS
PH01 R967 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PH01 R968 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PH01 R969 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PH01 R970 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PH01 R971 ns
p
00MNN05333610 CHIP RESISTOR 33K OHM +- 5% 1/16
W
PH01 R972 ns
p
00MNN05333610 CHIP RESISTOR 33K OHM +- 5% 1/16
W
PH01 R973 ns
p
00MNN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16
W
PH01 R974 ns
p
00MNN05473610 CHIP RESISTOR 47K OHM +- 5% 1/16
W
PH01 R975 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PH01 R976 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PH01 R977 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PH01 R978 ns
p
00MNN05101610 CHIP RESISTOR 100 OHM +- 5% 1/16
W
PH01 R979 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
