154
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PM01 LK29 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK30 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK31 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK32 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LK33 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LK34 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK35 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LK36 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LK37 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LK38 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LM01 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LM02 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LM03 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PM01 LM04 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PM01 LM05 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PM01 LM06 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LM07 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LM08 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LM09 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 LM10 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LN01 /N1B 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LN01 /N1S 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LN02 /N1B 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LN02 /N1S 00MFN31010060 00MFN31010060 EMI FILTER EMI FILTER BLM11P600S
PM01 LN03 /N1B 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PM01 LN03 /N1S 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PM01 LN04 /N1B 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PM01 LN04 /N1S 00MLU12103010 00MLU12103010 CHIP INDUCTANCE NL322522-100
K
PM01 LU01 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PM01 LU02 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PM01 LU03 00MFC90020110 00MFC90020110 FERRITE CORE BLM11B601S CHIP FERRITE
PM01 Q101 00MHC11039200 00MHC11039200 IC M65776BFP
PM01 Q102 00MHC11040200 00MHC11040200 IC M32102S6FP
PM01 Q103 00MHS21AKM10F 00MHS21AKM10F ONE TIME PROM M5M29GB320VP
PM01 Q104 00MHC12250990 00MHC12250990 IC W986416DH-7
PM01 Q105 00MHC10016350 00MHC10016350 IC SM8707EV
PM01 Q108 00MHC000337K0 00MHC000337K0 IC SN74LV138AP
W
PM01 Q109 00MHC000437K0 00MHC000437K0 IC SN74LV273ANS
PM01 Q111 00MHC000137K0 00MHC000137K0 IC SN74LV04APWR
PM01 Q112 00MHC700405Z0 00MHC700405Z0 IC TC7SU04F
PM01 Q113 00MHC10431990 00MHC10431990 IC AT24C04N-10SI-2.5
(
SHRINK
)
PM01 Q114 00MHC96J33210 00MHC96J33210 IC BA033FP 3.3V 1A PD=1W VD=0.3
V
PM01 Q115 00MHC98J18210 00MHC98J18210 IC BA18BC0FP-E2 1.8V REG.
PM01 Q116 00MHC98907320 00MHC98907320 IC ! PQ070XZ01ZP
PM01 Q117 00MHC96J33210 00MHC96J33210 IC BA033FP 3.3V 1A PD=1W VD=0.3
V
PM01 Q118 00MHC98J18210 00MHC98J18210 IC BA18BC0FP-E2 1.8V REG.
PM01 Q119 00MHC98907320 00MHC98907320 IC ! PQ070XZ01ZP
PM01 Q203 00MHC000537K0 00MHC000537K0 IC SN74LV244AP
W
PM01 Q204 00MHC010805K0 00MHC010805K0 IC TC74VHC157AF
PM01 Q205 00MHC010805K0 00MHC010805K0 IC TC74VHC157AF
PM01 Q206 00MHC010805K0 00MHC010805K0 IC TC74VHC157AF
PM01 Q207 00MHC005805K0 00MHC005805K0 IC TC74VHC157FT TAPING
PM01 Q301 00MHC10021880 00MHC10021880 IC CS494003-CQ
PM01 Q302 90M-HS21AKX0R 90M-HS21AKX0R IC 4M FLASH FPT-48P-M19
PM01 Q303 00MHC10004910 00MHC10004910 IC K4S161622D-TC60
PM01 Q304 00MHC10019880 00MHC10019880 IC CS8420-CS
PM01 Q305 00MHC10017350 00MHC10017350 IC SM5819AF
PM01 Q306 00MHC010505K0 00MHC010505K0 IC TC74VHCT32AFT
PM01 Q307 00MHC005805K0 00MHC005805K0 IC TC74VHC157FT TAPING
PM01 Q308 00MHC700801P0 00MHC700801P0 IC HD74LVC08
PM01 Q401 00MHC10081250 00MHC10081250 IC CXD2753R DSD DSP
PM01 Q402 00MHC10156990 00MHC10156990 IC EM636165TS-7
PM01 Q403 00MHC10209990 00MHC10209990 IC AD8062 2-CH HIGH-SPEED AMP
PM01 Q404 00MHC12249990 00MHC12249990 IC EPM3128ATC100-10
PM01 Q405 00MHC000137K0 00MHC000137K0 IC SN74LV04AP
W
PM01 Q501 00MHC10083250 00MHC10083250 IC CXD1881AR
PM01 Q502 00MHC10084250 00MHC10084250 IC CXD1885Q
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
