Marantz DV9500 - Page 157

155
NOTE : “nsp” PARTS IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PM01 Q503 00MHC10210990 00MHC10210990 IC M11L6161SA 1MX16ED0 RAM
PM01 Q505 00MHC10178020 00MHC10178020 IC AN8471SA-E1
PM01 Q507 00MHC700805S0 00MHC700805S0 IC TC7S08F TOSHIBA TAPING
PM01 Q508 00MHC10018110 00MHC10018110 IC FAN8042
PM01 Q510 00MHX211322A0 00MHX211322A0 CHIP TR. 2SB1132Q,R
PM01 Q511 00MHX211322A0 00MHX211322A0 CHIP TR. 2SB1132Q,R
PM01 Q512 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 Q950 00MHC10013880 00MHC10013880 IC CS4392-KS 24BIT 192KHZ DAC
PM01 QK01 00MHC10019660 00MHC10019660 IC CD0040AF I/P CONVERTER
PM01 QK03 00MHC10001910 00MHC10001910 IC K4S643232E-TC60 64M SDRAM
PM01 QK04 00MHC006105K0 00MHC006105K0 IC TC74VHC541FT TAPING
PM01 QK05 00MHC006105K0 00MHC006105K0 IC TC74VHC541FT TAPING
PM01 QK06 00MHC006105K0 00MHC006105K0 IC TC74VHC541FT TAPING
PM01 QK07 00MHC10384050 00MHC10384050 IC TC7S66FU
PM01 QK08 00MHC10384050 00MHC10384050 IC TC7S66FU
PM01 QK09 00MHC10440050 00MHC10440050 IC TC7SH08FU 932211931682
PM01 QK10 00MHC006105K0 00MHC006105K0 IC TC74VHC541FT TAPING
PM01 QK11 00MHC006105K0 00MHC006105K0 IC TC74VHC541FT TAPING
PM01 QK12 00MHC10440050 00MHC10440050 IC TC7SH08FU 932211931682
PM01 QK91 00MHC91903210 00MHC91903210 IC BA033SFP 3.3V WITH-SW LOW-SATU
PM01 QK92 00MHC10228210 00MHC10228210 IC BA25BC0WFP 2.5V REG.
PM01 QM01 00MHC10090840 00MHC10090840 IC ADV7314 VIDEO ENCODER
PM01 QM02 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QM03 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QM04 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QM05 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QM06 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QM07 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QM08 00MHC10440050 00MHC10440050 IC TC7SH08FU 932211931682
PM01 QM91 00MHC10228210 00MHC10228210 IC BA25BC0WFP 2.5V REG.
PM01 QN01 /N1B 00MHC10089840 00MHC10089840 IC ADV7310KST VIDEO ENCODER
PM01 QN01 /N1S 00MHC10089840 00MHC10089840 IC ADV7310KST VIDEO ENCODER
PM01 QN02 /N1B 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QN02 /N1S 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QN03 /N1B 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QN03 /N1S 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QN04 /N1B 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QN04 /N1S 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QU01 00MHS21AKH00F 00MHS21AKH00F ONE TIME PROM PANEL MICROPROCESSOR VER.1.00
PM01 QU02 00MHC10431990 00MHC10431990 IC AT24C04N-10SI-2.5
(
SHRINK
)
PM01 QU03 00MHC10229210 00MHC10229210 IC BD4727G RESET IC 2.7
V
PM01 QU04 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 QU05 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 QU06 00MHX100012A0 00MHX100012A0 CHIP TR. 2SA1586
(
Y,GR
)
2SA1576A
(
Q,R
)
PM01 QU07 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PM01 QU08 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PM01 QU09 00MBA10026210 00MBA10026210 SEMICON.COMP DTA114EU
PM01 QU10 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PM01 QU15 00MBA20035210 00MBA20035210 SEMICON.COMP DTC114EU
PM01 QU16 00MHX300012A0 00MHX300012A0 CHIP TR. 2SC4081
(
Q,R
)
2SC4116
(
Y,GR
)
PM01 QU91 00MHC98203090 00MHC98203090 IC NJU7222U33 3.3V REG.
PM01 R101 ns
p
00MNN05220610 CHIP RESISTOR 22 OHM +- 5% 1/16
W
PM01 R102 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R105 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PM01 R106 ns
p
00MNN05472610 CHIP RESISTOR 4.7K OHM +- 5% 1/16
W
PM01 R107 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R108 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R110 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R111 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R112 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R113 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R114 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PM01 R115 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R116 ns
p
00MNN05000610 CHIP RESISTOR 0 OHM +- 5% 1/16
W
PM01 R117 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
PM01 R119 ns
p
00MNN05102610 CHIP RESISTOR 1K OHM +- 5% 1/16
W
PM01 R120 ns
p
00MNN05103610 CHIP RESISTOR 10K OHM +- 5% 1/16
W
DESCRIPTION
P.C.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MJI)
PART NAME
